Heat Shrink Tubing HA47 19/6 mm Black 1 m

Hellermann 321-50190 TREDUX HA47 thick-walled, with adhesive, black 1m.

Manufacturer part number (MPN)

321-50190

EAN / GTIN

4031026239866

Sales unit

pcs

Package quantity

10 pcs

OEM part description

TREDUX-HA47-19/6-PO-X-BK

Type

TREDUX-HA47-19/6

Product family

TREDUX HA47 - thick wall adhesive lined

Serration

Thick-Wall

Material

Polyolefin, cross-linked (PO-X)

Colour

Black (BK)

Length

1.0 m

Wall thickness

2.7 mm

Supplied diameter (min.)

19.0 mm

Recovered diameter (max.)

6.0 mm

Operating temperature

-55 °C to +110 °C

Halogen-free

Yes

RoHS compliant

Yes

ELV compliant (Article 4-2)

Yes

UL recognised (US and Canada)

No

Hazardous goods

No

Weight per unit

0.08097 kg

Packed in

pcs.

Inner pack quantity

10

Inner pack type

carton

Country of origin

CN

Customs tariff number

39173200

ETIM 9.0 class

EC000217

UNSPSC code

39121723

Printable

No

Shrink Ratio

up to 4:1

Voltage range

Low Voltage

With inner glue (Yes/No)

Yes

For Object Outside Diameter

8.6-16.4 mm

Longitudinal Change After Shrinkage

-10% max.

Nominal ⌀

19 mm

Wire Size Range (mm²)

8.6-16.4 mm²

Model

Thick-walled

Wall thickness after shrinking

2.7 mm

Inner diameter before heat-shrink

19 mm

Inner diameter after heat-shrink

6 mm

Transparent

No

Shrink rate

4:1

UL approval

No

HS Code

3917.32

• EAN 4031026239866
• SAP 1000064588
• Code 8551837
