Heat Shrink Tubing HIS3 18.0/6.0 mm 4 m Clear

Hellermann 308-31803 HIS3 Heat-shrink tubing in dispenser box clear. 18,0/6,0mm 4m box.

Manufacturer part number (MPN)

308-31803 EAN / GTIN: 4031026218922 Sales unit: pcs OEM part description: HIS-3-18/6-PO-X-CL Type: HIS-3-18/6 Product family: HIS-3 Serration: Thin-Wall material: Polyolefin, cross-linked (PO-X) Colour: Transparent (CL) Length: 4 m Wall thickness: 0.90 mm Supplied diameter (min.): 19.1 mm Recovered diameter (max.): 6.0 mm Operating temperature: -55 °C to +135 °C Halogen-free: Yes RoHS compliant: Yes ELV compliant (Article 4-2): Yes Standards: C22.2 no. 198.1-06 Hazardous goods: No Weight per unit: 0.152 kg Package content: 4 m Packed in: pcs. Inner pack quantity: 1 Inner pack type: carton Country of origin: CN Customs tariff number: 39173200 ETIM 9.0 class: EC000217 UNSPSC code: 39121723 Behaviour At Low Temperature: not cracking Behaviour at Heat Shock: not fluid, not dripping, not cracking Behaviour at low Temperature test method: UL 224 Elongation At Heat Aging: 400 % Heat Aging Test: 168h/175°C Heat Aging test method: UL 224 Heat Shock Test: 4h/250°C minimum Tensile Strength At Heat Aging: 13 MPa Model: Thin-walled Wall thickness after shrinking: 0.9 mm Inner diameter before heat-shrink: 18 mm Inner diameter after heat-shrink: 6 mm Transparent: Yes Printable: No With inner glue: No Shrink rate: 3:1 UL approval: No

HS Code

3917.32

• EAN 4031026218922
• SAP 1000016738
• Code 8143783
