Wall-mount cabinet, H1355XB335XD275MM, IP34, alu (2468285)
Pricing
Request a quote
We reply within 24 hours
Product Description
Hager 2468285 cabinet H 1355 × W 335 × D 275 mm (including 210 mm plinth), protection class I with N and PE terminals, aluminium, black RAL 9005.
Technical Specifications
- Manufacturer part number (MPN)
- 2468285
- Sales unit
- pcs
- Package quantity
- 6 pcs
- IP rating
- IP34
- Mounting method
- Surface mounted
- Colour
- Grey
- Width
- 335 mm
- UV resistant
- No
- Height
- 1355 mm
- Depth
- 275 mm
- RAL-number
- 9005
- With mounting plate
- No
- Built-in depth
- 275 mm
- Number of rows
- 7
- Built-in height
- 1050 mm
- Type of covering
- Door
- Built-in width
- 250 mm
- EMC-version
- No
- Extension possible
- No
- Inner depth
- 270 mm
- DIN-rail
- No
- Housing material
- Aluminium
- Width in number of modular spacings
- 12
- Type of closure
- Three-square
- Type of door
- Single
- Degree of protection (IP)
- IP34
- Transparent cover/door
- No
- With lock
- Yes
- Cover model
- Closed
- Earthing terminal block
- No
- Neutral terminal block
- No
- Signal passing door
- No
- Country of origin
- Norway
Standards & Compliance
- HS Code
- 8538.10
Cross References
- 7090006743929
Product Documentation
More from Hager Systemer
Hager Systemer
Slotted Trunking HALOGEN-FREE 100X60 L.GREY L=2M
HA7100060
Hager Systemer
Flat angle for LF channel 60X110 WHITE
LFF6011059016
Hager Systemer
Hager Systemer Slotted Cable Duct, 36x50, Halogen-Free, Blue
HNG37050BL
Hager Systemer
Delta hybrid, met, inf, 2X26M
1705820
Hager Systemer
Senterbrikke white for single data
WXD201B
Hager Systemer
Steel Flange IP44 M16-20-25-32-40
2471699
Hager Systemer
Hager Systemer Internal corner for LFF 60x60 mm trunking, moulded ABS, traffic white RAL 9016, adjustable 83...97 deg LFF6006049016
Hager Systemer
Hager Systemer Internal corner for LFF 60x110 mm trunking, moulded ABS, traffic white RAL 9016, adjustable 83...97 deg LFF6011049016
Catalogue entry last verified: 2026-10-02. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 2468285?
- 2468285 can be ordered from cballast.com as a Hager Systemer catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Hager Systemer product?
- The manufacturer part number is 2468285.
- What is the HS code for 2468285?
- The customs tariff (HS) code for 2468285 is 8538.10.
- Who manufactures 2468285?
- 2468285 is a Hager Systemer product in the Enclosures range.
- Is a datasheet available for 2468285?
- Yes — the 2468285 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 2468285?
- The minimum order quantity is 1.
- Is 2468285 available?
- Yes — 2468285 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
