Hager Systemer EE815 Ceiling-Mounted 360 Degree Presence Detector
Pricing
Request a quote
We reply within 24 hours
Product Description
Hager Systemer EE815 is a passive infrared presence detector for flush ceiling mounting, with a full 360 degree detection field. Frontal reach is 7 m and lateral reach 6 m at an optimum mounting height of 4 m, with adjustable luminosity threshold and teach function. It is networkable, supports remote operation and offers IP41 protection in a white thermoplastic housing.
Technical Specifications
- Manufacturer part number (MPN)
- EE815
- EAN / GTIN
- 3250617579193
- Sales unit
- pcs
- Mounting method
- Flush-mounted
- Colour
- White
- Model
- Presence detector
- Halogen free
- Yes
- Creep-under protection
- No
- Frequency
- 50–60 Hz
- With remote control
- No
- Staircase light controller
- No
- Bridging switch
- No
- Suitable for wireless transmission
- No
- Material quality
- Thermoplastic
- Max. reach frontally
- 7 m
- Max. reach sideways
- 6 m
- Max. starting current
- 16 A
- Material
- Plastic
- Response value sensitivity adjustable
- Yes
- Dim function with dimmer basic element
- No
- Diameter reach on floor
- 7 m
- Remote operation
- Yes
- HVAC-control
- No
- Constant light control
- No
- Substation input
- Yes
- RAL-number (similar)
- 9001
- With signal unit
- No
- Teach-function for response value luminosity
- Yes
- Networkable
- Yes
- Forced switch off
- No
- Scan angle
- 360 °
- Degree of protection (IP)
- IP41
- Animal zone
- No
- Surface finishing
- Matt
- Detection angle horizontal
- 360 °
- Min. switch-on time
- 60 s
- Max. duty cycle
- 60 min
- Suitable for wall mounting
- No
- Response value luminosity adjustable
- Yes
- Optimum mounting height
- 4 m
- Constant light output (CLO)
- No
- With DALI interface
- No
- IFTTT support available
- No
- Compatible with Apple HomeKit
- No
- Compatible with Google Assistant
- No
- Compatible with Amazon Alexa
- No
- Sensor type
- Passive infrared
- Anti-bacterial treatment
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3250617579193
- SAP 1000479451
- Code 8854993
