Hager Systemer WXF473B 3-Way Socket Gallery, White, 45x45
Pricing
Request a quote
We reply within 24 hours
Product Description
Hager Systemer WXF473B 3-way socket gallery in white 45x45 format, rated 16 A at 250 V. Metal-body flush-mount enclosure with snap fastening, matt lacquered finish, IK05 impact rating and IP21 protection. Enhanced contact protection and screwed terminals; six modular units wide. Manufactured in Germany.
Technical Specifications
- Manufacturer part number (MPN)
- WXF473B
- EAN / GTIN
- 3250617130172
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 70 pcs
- Nominal current
- 16 A
- Nominal voltage
- 250 V
- Colour
- White
- Halogen free
- No
- Number of units
- 3
- Lockable
- No
- With hinged lid
- No
- Connection type
- Screwed terminal
- With signal lamp
- No
- Number of phases
- 2
- With enhanced contact protection
- Yes
- Frequency
- 50–60 Hz
- With on/off switch
- No
- Label space/information surface
- No
- Eject-mechanism
- No
- Rotated central insert
- No
- Overvoltage protection
- No
- Fault current protection
- No
- Special power supply
- No special power supply
- Insulated mounting
- Yes
- Material
- Metal
- Type of fastening
- Snap mounting (engagement)
- Imprint/indication
- None
- RAL-number (similar)
- 9016
- Impact strength
- IK05
- Transparent
- No
- Surface finishing
- Matt
- With miniature fuse
- No
- With loop through function
- No
- Suitable for degree of protection (IP)
- IP21
- Device width
- 135 mm
- Device height
- 42.5 mm
- Device depth
- 45 mm
- With function lighting
- No
- With orientation lighting
- No
- Number of modules (module system)
- 6
- IFTTT support available
- No
- Number of active contacts (flat)
- 2
- Min. depth of built-in installation box
- 50 mm
- Compatible with Apple HomeKit
- No
- Compatible with Google Assistant
- No
- Compatible with Amazon Alexa
- No
- Metallic colour
- No
- Anti-bacterial treatment
- No
- Country of origin
- Germany
