Tube elbow SPBE40 FE-TI-90-150 SS
Pricing
Request a quote
We reply within 24 hours
Product Description
Tube elbow SPBE40 FE-TI-90-150 SS. Flat elbow 90º for tubing installations with integrated splice connectors. Overall dimensions 197 × 197 mm (X × Y), material thickness 1.5 mm, height 41 mm, width 152 mm, radius 65 mm, angle 90°, weight 0.580 kg. ETIM class EC002400 (Bend for cable tray).
Technical Specifications
- Manufacturer part number (MPN)
- SPBE40 FE-TI-90-150 SS
- EAN / GTIN
- 7070693718424
- Sales unit
- pcs
- Type
- Tubing Bend
- T Material Thickness (mm)
- 1.5
- X (mm)
- 197
- Y (mm)
- 197
- W Width (mm)
- 152
- H Height (mm)
- 41
- Radius
- 65
- A Angle (deg)
- 90
- O Overlap Integrated Splice (mm)
- 32
- Fits Tray Width (mm)
- 150
- Weight (kg)
- 0.580
- ETIM class
- EC002400 - Bend for cable tray
- Manufacturer item number
- 1371842
- Hilti item number
- 2307453
- Change of direction
- Horizontal
- Construction type
- Bend rigid
- Bend model
- Smooth bend
- Inner radius
- 65 mm
- Suitable for cable tray height
- 40 mm
- Suitable for cable tray width
- 150 mm
- Material thickness
- 1.5 mm
- Side perforation
- No
- Bottom perforation
- Yes
- Model
- Integrated connector
- Wide span model
- No
- Material
- Stainless steel
- Stainless steel, pickled
- No
- Material quality
- Rustproof and acidproof steel
- Colour
- None
- Country of origin
- Norway
Standards & Compliance
- HS Code
- 7308.90
Cross References
- EAN 7070693718424
- SAP 1000058798
- Code 8908501
Product Documentation
More from Øglænd System
Øglænd System
FOE-70 TE-500/500 R300
T-PIECE FOE-70 TE-500/500-R3
Øglænd System
Øglænd System OE100 Cable Ladder, R600
OE100 CP-600 R600
Øglænd System
Øglænd System OER300 Rack, 1800 × 1990 mm, Stainless Steel
OER300-RIO RK-1800-1990 SS
Øglænd System
Øglænd System SmartCleat Cable Cleat, TPV
1301546
Øglænd System
Øglænd System LOE Starter Bracket, 80 mm, Stainless Steel
LOE ST-BO-CS-222 SS
Øglænd System
Øglænd System SPBE20 Flat Elbow 90°, 500 mm, R75, Stainless Steel
SPBE20 FE90-500-R75 SS
Øglænd System
Øglænd System INKO-O Tube Clamp, ME10/IM3/8", Stainless Steel/PP
1320310
Øglænd System
Øglænd System Mekano Cantilever Arm, 300 mm, Pre-Galvanised
Mekano CA-NO-50-300 PG
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy SPBE40 FE-TI-90-150 SS?
- SPBE40 FE-TI-90-150 SS can be ordered from cballast.com as a Øglænd System catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Øglænd System product?
- The manufacturer part number is SPBE40 FE-TI-90-150 SS.
- What is the HS code for SPBE40 FE-TI-90-150 SS?
- The customs tariff (HS) code for SPBE40 FE-TI-90-150 SS is 7308.90.
- Who manufactures SPBE40 FE-TI-90-150 SS?
- SPBE40 FE-TI-90-150 SS is a Øglænd System product in the Cables & Wiring range.
- Is a datasheet available for SPBE40 FE-TI-90-150 SS?
- Yes — the SPBE40 FE-TI-90-150 SS datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for SPBE40 FE-TI-90-150 SS?
- The minimum order quantity is 1.
- Is SPBE40 FE-TI-90-150 SS available?
- Yes — SPBE40 FE-TI-90-150 SS is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
