Gems LS-1750 Single-Point Float Switch, 316SS, 1/8 NPT
Pricing
Request a quote
We reply within 24 hours
Product Description
Single-point side-mounted miniature liquid level switch. Stem-and-collar design with a swing-arm float; SPST reed actuated by an internal magnet. Specified for hydraulic reservoirs, gearbox oil tanks, bilge alarms and small process vessels where space is constrained.
Technical Specifications
- Mounting
- 1/8 NPT side, brass collar. Wetted: 316 stainless steel. Switch: SPST reed
- 20 VA. Voltage
- up to 240 V AC/DC. Operating temp: -29 to +93 °C. Pressure: up to 17 bar. Float OD: 27 mm.
Standards & Compliance
- Material
- 316 stainless steel float, brass mount, FKM seal
- Pressure Rating
- 17 bar
- Temperature Range
- -29°C to +93°C
- HS Code
- 8531.80
Product Documentation
