Surge protection device PSC3-7,5/400 TNC IR
Pricing
Request a quote
We reply within 24 hours
Product Description
Function CP77738315 Surge protection device PSC3-7,5/400 TNC IR.
Technical Specifications
- Manufacturer part number (MPN)
- CP77738315
- EAN / GTIN
- 7070587118248
- Sales unit
- pcs
- System configuration DC
- No
- System configuration IT
- No
- System configuration TN
- Yes
- System configuration TN-C
- Yes
- System configuration TT
- Yes
- Number of conductors (without earthing)
- 3
- Nominal discharge surge current (8/20)
- 20 kA
- Max. discharge surge current (8/20)
- 65 kA
- Max. continuous voltage AC
- 275 V
- Voltage protection level L-N
- 1.3 kV
- Short-circuit breaking capacity (Isccr)
- 25 kA
- Integrated backup fuse
- No
- Mounting method
- DIN rail (top hat rail) 35 mm
- Construction size
- 3 modular spacing
- Max. conductor cross section solid (solid, stranded)
- 25 mm²
- Max. conductor cross section flexible (fine-strand)
- 25 mm²
- With remote signalling contact
- Yes
- Signalling at the device
- Optical
- Category type 2
- Yes
- Degree of protection (IP)
- IP20
- Country of origin
- Spain
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 7070587118248
- SAP 1200780481
- Code 83939724
Product Documentation
