Function LA1094BT Annual Time Switch MM7587 2-Channel 12-24 V AC/DC, Bluetooth
Pricing
Request a quote
We reply within 24 hours
Product Description
Function LA1094BT is a two-channel annual time switch (model MM7587) operating on 12-24 V AC or DC with a Bluetooth programming interface. It supports 60-minute, 24-hour, weekly, annual, holiday, impulse, cycle, astro and random programs with GPS synchronisation and 300 memory locations. The unit mounts on DIN rail at 4 modules wide and provides change-over contacts rated 16 A at 250 V AC. Typical use is scheduled control of lighting, HVAC or process circuits.
Technical Specifications
- Manufacturer part number (MPN)
- LA1094BT
- EAN / GTIN
- 4022709241115
- Sales unit
- pcs
- Voltage
- 12-24 V
- Mounting method
- DIN rail
- Number of channels
- 2
- Supply voltage
- 12–24 V
- Voltage type (supply voltage)
- AC/DC
- Autonomy in hours
- 87600
- Autonomy in years
- 10
- Accuracy per day
- 1 s
- Text guidance in display
- Yes
- External programming
- Yes
- With memory card
- No
- 60 min program
- Yes
- 24 h program
- Yes
- Weekly program
- Yes
- Annual program
- Yes
- Holiday program
- Yes
- Impulse program
- Yes
- Cycle program
- Yes
- Astro program
- Yes
- Random program
- Yes
- Hour meter
- Yes
- Mains synchronous
- No
- Quartz controlled
- Yes
- Radio-controlled
- No
- GPS (global positioning system)
- Yes
- Contact type
- Change-over contact (NO/NC)
- Number of memory locations
- 300
- Automatic switching summer/winter time
- Yes
- Suitable for manual operation
- Yes
- External push button input
- Yes
- Switching preselection
- Yes
- Nominal switching current at 250 V AC
- 16 A
- Max. switching power LED
- 200 W
- Potential free switch contact
- Yes
- Degree of protection (IP)
- IP20
- Width in number of modular spacings
- 4
- Width
- 71.5 mm
- Height
- 90 mm
- Depth
- 58 mm
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 9107.00
Cross References
- EAN 4022709241115
- SAP 1200478370
- Code 82552147
Product Documentation
