Fluke 754 Pressure Module 700PRV1 -25 to +25 INH2O

Fluke 700PRV1 pressure module -25 to +25 inH2O for 754 calibrator. For very-low-pressure air flow and HVAC applications. Used by maintenance technicians and installation crews across industrial, marine and construction service.

Type

700PRV1 pressure module

Range

-25 to +25 inH2O

Accuracy

±0.05% F.S.

Manufacturer model

Fluke 754

Voltage AC

3.000 V (40 Hz to 500 Hz) / 0.001 V 0.5% + 0.002 V 1.0% + 0.004 V

30.00 V (40 Hz to 500 Hz) / 0.01 V

0.5% + 0.02 V 1.0% + 0.04 V

300.0 V (40 Hz to 500 Hz) / 0.1 V

0.5% + 0.2 V 1.0% + 0.2 V

Current DC

30.000 mA 0.01% + 5 uA 0.015% + 7 uA

Resistance

10.000 Ω 0.05% + 50 mΩ 0.07% + 70 mΩ

Frequency

1.00 to 110.00 Hz / 0.01 Hz 0.05 Hz

Voltage DC

100.000 mV 0.01% + 0.005 mV 0.015% + 0.005 mV

Current sink (simulate)

0.02% + 0.007 mA 0.04% + 0.007 mA

Data log functions

Measure functions Voltage, current, resistance, frequency, temperature, pressure

Reading rate

1, 2, 5, 10, 20, 30, or 60 readings/minute

Maximum record length

8000 readings (7980 for 30 or 60 readings/minute)

Ramp functions

Source functions Voltage, current, resistance, frequency, temperature

Rate

4 steps/second

Trip detect

Continuity or voltage (continuity detection not available when sourcing current)

Loop power function

Voltage Selectable, 26 V

HS Code

9030.39
