Festo VUVS-L30-M32U-MD-G38-F8-1B2 Solenoid valve

Festo VUVS-L30-M32U-MD-G38-F8-1B2 — Solenoid valve, universal directional control valves. valve function 3/2-way, single solenoid, open; operating pressure 0.25. 1 MPa (2.5. 10 bar); nominal size 9.4 mm.

Manufacturer part number (MPN)

575589

Type code

VUVS-L30-M32U-MD-G38-F8-1B2

EAN / GTIN

4052568261269

Product category

Universal directional control valves

Valve function

3/2-way, single solenoid, open

Type of actuation

Electrical

Valve size

31 mm

Standard nominal flow rate (standardised to DIN 1343)

2300 l/min

pneumatic working port

G3/8

Operating voltage

24 V DC

Operating pressure

0.25 ... 1 MPa (2.5 ... 10 bar)

Design

Piston gate valve

Type of reset

Mechanical spring

Approval

c UL us - Recognised (Oil)

Maritime classification

See certificate

Certificate issuing authority

DNVGL-TAA000011J

Degree of protection

IP65, with plug socket, To IEC 60529

Nominal size

9.4 mm

Exhaust-air function

Can be throttled

Sealing principle

Soft

Mounting position

Any

Manual override

Detenting, Non-detenting

Type of piloting

Piloted

Pilot air supply

Internal

Flow direction

Non-reversible

Symbol

00991140

lap

Overlap

b value

0.3

C value

9.2 l/sbar

Switching time off

57 ms

Switching time on

15 ms

Duty cycle

100%

Max. positive test pulse with 0 signal

2000 µs

Max. negative test pulse with 1 signal

3600 µs

Characteristic coil data

24 V DC: 3.3 W

Permissible voltage fluctuations

+/-10%

Operating medium

Compressed air to ISO 8573-1:2010 [7:4:4]

Vibration resistance

Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6

Shock resistance

Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27

Corrosion resistance class CRC

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Cleanroom suitability, measured according to ISO 14644-14

Class 6 according to ISO 14644-1

Media temperature

-10 ... 60 °C

Pilot medium

Compressed air to ISO 8573-1:2010 [7:4:4]

Ambient temperature

-10 ... 60 °C

Product weight

405 g

Electrical connection

Type B, To industry standard (11 mm)

Type of mounting

On manifold rail, with through-hole

Breather connection

Not ducted

Pilot exhaust port 82

M5

Pneumatic connection, port 1

G3/8

Pneumatic connection, port 2

G3/8

Pneumatic connection, port 3

G3/8

Material seals

HNBR, NBR

Material housing

Die-cast aluminium, painted

Material piston slide

Wrought aluminium alloy

Material screws

Nickel-plated steel

Product type

Pneumatic solenoid valves

Product group

Pneumatics

Thread

G3/8"

Activation

El

Return

Spring

Temperature min

-10 °C

Temperature max

60 °C

Working pressure

10 bar

Carbon footprint (EPD)

9.7379 kg CO2e per pcs

Country of origin

China

Customs tariff code (EU CN)

84812090

HS code

8481.20

HS Code

8481.20

• EAN 4052568261269
• MPN 575589
