Eltako ER12-110-12..230V UC Electronic Relay 1 NO + 1 NC, 16 A / 250 V AC
Part numberER12-110-12..230V UCEAN / GTIN4010312205440HS code8536.90
Control & Automation
Relays & Timers
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Eltako ER12-110-12..230V UC partially electronic operating-current relay with a 10-230 V AC/DC control input and one changeover contact rated 16 A at 250 V AC. DIN-rail mount, 1 module wide, 58 mm deep.
Technical Specifications
- Manufacturer part number (MPN)
- ER12-110-12..230V UC
- EAN / GTIN
- 4010312205440
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Rated current
- 16 A
- Contact configuration
- 1 NO + 1 NC
- Function
- Partially electronic
- Mounting method
- DIN rail
- Width in number of modular spacings
- 1
- Built-in depth
- 58 mm
- Number of contacts as normally open contact
- 1
- Number of contacts as normally closed contact
- 1
- Control voltage 1
- 12–230 V
- Type of control voltage 1
- AC/DC
- Frequency control voltage 1
- 50 Hz
- Type of control voltage 2
- AC/DC
- Supply voltage
- 250 V
- Voltage type (supply voltage)
- AC
- Max. incandescent lamp load
- 2000 W
- Max. load fluorescent lamp
- 1000 VA
- Max. switching current (cos phi = 0.6)
- 4 A
- Country of origin
- China
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4010312205440
- SAP 1000431758
- Code 833427
Product Documentation
Document preview: Eltako ER12-110-12..230V UC Electronic Relay 1 NO + 1 NC, 16 A / 250 V AC — Specification sheet
