Elpress
Elpress SC630R Shearbolt Connector, Reversible Screw
Part numberSC630REAN / GTIN7393487033788HS code8536.90
Fasteners & Hardware
Screws & Bolts
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Elpress SC630R Skruvskarvhylse.
Technical Specifications
- Manufacturer part number (MPN)
- SC630R
- EAN / GTIN
- 7393487033788
- Sales unit
- pcs
- Article number
- 7320-010600
- Type designation
- SC630R
- d (mm)
- 33
- L (mm)
- 210
- s (mm) - strip length
- 106
- Max voltage (kV)
- 1-36
- Cable type Round (mm²)
- 500-630
- Nominal cross section copper, RM, Min (mm²)
- 500
- Nominal cross section copper, RM, Max (mm²)
- 630
- Nominal cross section copper, RE, Min (mm²)
- 500
- Nominal cross section aluminium, RE, Max (mm²)
- 630
- Pieces per pack
- 1
- Net weight (kg)
- 1.125
- Height Pack (mm)
- 49
- Depth Pack (mm)
- 345
- Width Pack (mm)
- 185
- Number of screws
- 10
- Oil stop/centre bar
- Yes
- Conductor material
- Aluminium/copper
- Voltage level
- Up to 36 kV
- Nominal cross section copper, RM
- 500–630 mm²
- Nominal cross section copper, RE
- 500–630 mm²
- Nominal cross section aluminium, RM
- 500–630 mm²
- Nominal cross section aluminium, RE
- 500–630 mm²
- Material conductor
- Aluminium/copper
- With insulation
- No
- Country of origin
- Sweden
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7393487033788
- SAP 1000023948
- Code 8184263
Product Documentation
Document preview: Elpress SC630R Shearbolt Connector, Reversible Screw — Specification sheet
More from Elpress
Elpress
pliers Miniforce 10-25 Ändhylsor
GEB1025C
Elpress
Elpress Mains/battery hydraulic pump (PS710D)
Elpress
Elpress AKS70-50 Aluminium-Copper Bimetallic Through Connector 70 mm² Al / 50 mm² Cu
Elpress
pliers Miniforce TWIN 4-10 mm²
GEB4010C-TWIN
Elpress
Elpress Crimping die for RJ45 modular plugs
OMP45
Elpress
Elpress AKS240-150 Aluminium-Copper Bimetallic Through Connector 240 mm² Al / 150 mm² Cu
Elpress
Bakkeset for C-press
TBC89-B13
Elpress
Elpress SC400R240S Shearbolt Connector, Reversible Screw
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy SC630R?
- SC630R can be ordered from cballast.com as a Elpress catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Elpress product?
- The manufacturer part number is SC630R.
- What is the HS code for SC630R?
- The customs tariff (HS) code for SC630R is 8536.90.
- Who manufactures SC630R?
- SC630R is a Elpress product in the Fasteners & Hardware range.
- Is a datasheet available for SC630R?
- Yes — the SC630R datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for SC630R?
- The minimum order quantity is 1.
- Is SC630R available?
- Yes — SC630R is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
