Elpress KS2,5 Copper Compression Through Connector 2.5 mm²
Pricing
Request a quote
We reply within 24 hours
Product Description
Elpress KS2,5 — copper compression through connector (splice sleeve) for jointing 2.5 mm² copper conductors end to end. Formed from 99.95% electrolytic copper, tin-plated (Cu/Sn), with a cable inspection hole and internal cable stop. Accepts stranded (IEC 60228 Class 2) and flexible (Class 5/6) copper conductors. Crimped with matching Elpress dies to a gas-tight, low-resistance joint tested to IEC 61238-1. Approvals: UL File E205350.
Technical Specifications
- Type
- Copper compression through connector (splice sleeve)
- Conductor cross-section
- 2.5 mm²
- Conductor class
- Stranded (IEC 60228 Cl.2) & flexible (Cl.5/6) copper
- Material
- Electrolytic copper 99.95%, tin-plated (Cu/Sn)
- Feature
- Cable inspection hole, internal cable stop
- Crimp system
- System Elpress, tested to IEC 61238-1
- Approvals
- UL File E205350
- Manufacturer part number (MPN)
- KS2,5
- EAN / GTIN
- 7393487007857
- Sales unit
- pcs
- Package quantity
- 100 pcs
- HS code
- 8536.90
- Article number
- 7303-000400
- Type designation
- KS2,5
- d (mm)
- 2.3
- L (mm)
- 16
- s (mm) - strip length
- 8
- AWG/MCM Cu
- 16 - 14 AWG
- mm² Cu
- 2,5
- Model
- UL version
- Surface protection
- Tin plated
- Insulation
- EV000494
- AWG-range, Min
- 14
- AWG-range, Max
- 16
- Nominal cross section, Min (mm²)
- 2.5
- Suitable for fine strand conductors
- Yes
- Suitable for solid conductors
- Yes
- Suitable for stranded conductors
- Yes
- Suitable for round conductors
- Yes
- Sleeve form
- Short
- Pieces per pack
- 100
- Net weight (kg)
- 0.0013
- Height Pack (mm)
- 100
- Depth Pack (mm)
- 60
- Width Pack (mm)
- 22
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 7393487007857
- SAP 1000038606
- Code 8738038
Product Documentation
More from Elpress
Elpress
Elpress B4630SR Pin Terminal, 4-6 mm²
Elpress
Elpress A2565R
Elpress
B1502HO (7197-500600)
Elpress
Elpress KR6-8 Copper Tube Cable Lug 6 mm² M8
Elpress
Elpress KRF16-6-CP Copper Tube Cable Lug 16 mm² M6
Krf16-6-Cp
Elpress
Elpress A1553R
Elpress
Elpress KS0,75 Copper Compression Through Connector 0.75 mm²
Elpress
Elpress KRF50-10-45GR Copper 45° Angled Tube Cable Lug 50 mm² M10
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy KS2,5?
- KS2,5 can be ordered from cballast.com as a Elpress catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Elpress product?
- The manufacturer part number is KS2,5.
- What is the HS code for KS2,5?
- The customs tariff (HS) code for KS2,5 is 8536.90.
- Who manufactures KS2,5?
- KS2,5 is a Elpress product in the Electrical Components range.
- Is a datasheet available for KS2,5?
- Yes — the KS2,5 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for KS2,5?
- The minimum order quantity is 1.
- Is KS2,5 available?
- Yes — KS2,5 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
