ELKO
SPOT UP Multi 3 3000K
Part number7761560EAN / GTIN7392971124940HS code9405.42
Lighting & Electrical Accessories
Ceiling & Wall Luminaires
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
ELKO 7761560 Markarmatur with multichipteknologi and 25 degree reflector, 105lm. IP67 with 2m rubber cable.
Technical Specifications
- Manufacturer part number (MPN)
- 7761560
- EAN / GTIN
- 7392971124940
- Sales unit
- pcs
- Package quantity
- 30 pcs
- Colour temperature
- 3000 K
- Protection class according to IEC 61140
- I
- Outer diameter
- 55 mm
- Lamp power
- 3 W
- Suitable for loop-through wiring
- No
- Height
- 86 mm
- Lamp holder
- None
- Conductor cross section
- 1.5 mm²
- Housing colour
- Stainless steel
- Dimmable
- No
- Voltage type
- AC
- Built-in depth
- 83 mm
- Type of control gear
- LED operating device current-controlled
- Adjustable
- No
- Colour rendering index CRI
- 80-89
- Built-in diameter
- 46 mm
- Number of poles
- 3
- Height/depth
- 85 mm
- Housing material
- Aluminium
- Lamp type
- LED not exchangeable
- Electrical connection with connector system
- No
- Light distribution
- Symmetric
- Material cover
- Structured glass
- Over rollable
- Yes
- Max. surface temperature
- 40 °C
- Nominal voltage
- 230 V
- Degree of protection (IP)
- IP67
- With light source
- Yes
- Max. load
- 1220 kg
- Suitable for number of light sources
- 1
- With control gear
- Yes
- Beam angle
- 21-40° - Medium beam
- Max. system power
- 3 W
- Rated luminous flux according to IEC 62722-2-1
- 122 lm
- Colour of light
- White
- Type of wiring
- Ending
- Dimming 0-10 V
- No
- Dimming 1-10 V
- No
- Dimming DALI
- No
- Dimming DMX
- No
- Dimming potentiometer (integrated)
- No
- Dimming GPRS
- No
- Dimming LineSwitch
- No
- Dimming manufacturer's proprietary system
- No
- Dimming mains voltage modulation
- No
- Dimming phase cut-off (trailing edge)
- No
- Dimming phase cut-on (leading edge)
- No
- Dimming programmable
- No
- Dimming RF
- No
- Dimming Its Wave Reduction
- No
- Dimming Touch and Dim
- No
- Dimming Zigbee
- No
- Dimming with push-button
- No
- No dim function
- Yes
- Light distributor
- Focal lens
- Dimming DSI
- No
- Energy efficiency class of the built-in lamp
- A++, A+, A (LED)
- Built-in height/depth
- 82 mm
- Device emplacement
- Outdoor positioning
- Country of origin
- China
Standards & Compliance
- HS Code
- 9405.42
Cross References
- EAN 7392971124940
- SAP 1000647485
- Code 8193705
Product Documentation
Document preview: SPOT UP Multi 3 3000K (7761560) — Specification sheet
