Elis Elektro
Thread Adapter PG16/M20, Polyamide
Part number1254740EAN / GTIN7070613006297HS code3917.40
Electrical Components
Cable Glands
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Elis Elektro 1254740 Thread adapter PG16/M20, polyamide.
Technical Specifications
- Manufacturer part number (MPN)
- 1254740
- EAN / GTIN
- 7070613006297
- Sales unit
- pcs
- Package quantity
- 100 pcs
- Cable entry
- PG16
- Connection type to housing
- Screwing
- Thread type
- PG
- Nominal thread size metric/PG
- 16
- Pitch thread
- 1.5 mm
- Thread length
- 10 mm
- Wrench width
- 27 mm
- Hexagon angular dimension
- 27 mm
- Material
- Plastic
- Material quality
- Polyamide (PA)
- Surface protection
- Untreated
- Halogen free
- Yes
- Glass-fibre reinforced
- Yes
- Shock resistant
- No
- RAL-number
- 7035
- Bend radius protection/trumpet flare
- No
- With locknut
- No
- Snapping in opening
- No
- Multi seal area
- No
- Flat cable coupling
- No
- With strain relief
- Yes
- Separable screw gland
- No
- Operating temperature
- -30–100 °C
- Explosion-tested version
- No
- For Ex-zone gas
- None
- For armoured cable
- No
- EMC-version
- No
- Screened
- No
- Colour
- Grey
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 3917.40
Cross References
- EAN 7070613006297
- SAP 1200927210
- Code 84212284
Product Documentation
Document preview: Thread Adapter PG16/M20, Polyamide (1254740) — Specification sheet
