LIYCY 5X1,5 mm² (1001660)

Elis Elektro 1001660 LIYCY 5x1,5 mm².

Manufacturer part number (MPN)

1001660

EAN / GTIN

7070613019273

Sales unit

m

Package quantity

500 m

EL number

1001660

ETIM class

EC003250 - Power cable < 1 kV, for moving application

CE marked

Yes

REACH relevant

No

Country of origin

Germany

HS code

85441100

Base unit

m

Price unit

m

Product length / depth

1000 mm

Net weight

172 g

Price units per base unit

1

Nominal voltage U (V)

500

Nominal cross section conductor (mm²)

1.5

Nominal voltage U0 (V)

300

Nominal cross section conductor (AWG) (kcmil)

16

Cable width approximate (mm)

9.6

Cable height approximate (mm)

9.6

Number of cores

5

Weight (kg/km)

172

Min. permitted bending radius, moving application with forced guidance (mm)

45

Min. permitted bending radius, moving application/free movement (mm)

45

Outer diameter approximate (mm)

9.6

Min. permitted bending radius, stationary application/permanent installation (mm)

45

Permitted cable outer temperature during assembling/handling (°C)

-15 to 70

Permitted cable outer temperature after assembling without vibration (°C)

-30 to 80

Screen

Yes

With protective conductor

No

Torsion resistant

No

Low temperature resistant according to EN 60811-504+505+506

No

Low smoke according to EN IEC 61034-2

No

Halogen free according to EN IEC 60754-1

No

Halogen free according to EN IEC 60754-2

No

Oil resistant according to EN IEC 60811-404

No

HS Code

8544.49

• EAN 7070613019273
• SAP 1200827294
• Code 84015305
