Eaton
Over.m Darw fl/r.kab via kont
Part numberSWD4-SFL8-20EAN / GTIN4015081192090HS code8538.90
Control & Automation
I/O Modules
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton Over.m Darw fl/r.kab via kont (part number SWD4-SFL8-20) is listed under Control & Automation / I/O Modules. Sales unit: pcs; Eaton catalogue number: 121380; Depth: 41 mm; Height: 83 mm; Width: 35 mm; Weight: 0.045 kg.
Technical Specifications
- Manufacturer part number (MPN)
- SWD4-SFL8-20
- EAN / GTIN
- 4015081192090
- Sales unit
- pcs
- Eaton catalogue number
- 121380
- Depth
- 41 mm
- Height
- 83 mm
- Width
- 35 mm
- Weight
- 0.045 kg
- Certifications
- UL File No.: E29184; EN 50178; CSA File No.: 2324643; UL; CSA; CSA Class No.: 3211-07; IEC/EN 61131-2; UL Category Control No.: NKCR
- Constant acceleration
- 1 g, 8.4 - 150 Hz, according to IEC/EN 61131-2, Vibrations
- Constant amplitude
- 3,5 mm, 5 - 8.4 Hz, according to IEC/EN 61131-2, Vibrations
- Height of fall (IEC/EN 60068-2-32) - max
- 0.3 m
- Mounting position
- As required
- Shock resistance
- 15 g, Mechanical, according to IEC/EN 60068-2-27, Half-sinusoidal shock 11 ms, 9 Impacts
- Air pressure
- 795 - 1080 hPa (operation)
- Ambient operating temperature - max
- 70 °C
- Ambient storage temperature - max
- 70 °C
- Ambient operating temperature - min
- -25 °C
- Ambient storage temperature - min
- -40 °C
- Climatic proofing
- Dry heat to IEC 60068-2-2; Damp heat, constant, to IEC 60068-2-3
- Environmental conditions
- Condensation: prevent with appropriate measures
- Operating temperature - max
- 70 °C
- Operating temperature - min
- -25 °C
- Relative humidity
- 5 - 95 % (non-condensing, IEC/EN 60068-2-30)
- Connection type
- Connection 1: Plug, 8-pole; M20 socket, 8 pole
- Static heat dissipation, non-current-dependent Pvs
- 1 W
- Power loss
- 1 W
- Air discharge
- 8 kV, according to IEC 61131-2, level 3, ESD
- Contact discharge
- 4 kV, according to IEC/EN 61131-2, Level 2, ESD
- Electromagnetic fields
- 3 V/m at 1.4 - 2 GHz (according to IEC/EN 61131-2:2008); 1 V/m at 2.0 - 2.7 GHz (according to IEC/EN 61131-2:2008); 10 V/m at 80 - 1000 MHz (according to IEC/EN 61131-2:2008)
- Radiated RFI
- 10 V (IEC/EN 61131-2:2008, Level 3)
- Degree of protection
- IP20; IP20 (according to IEC/EN 60529, EN 50178, VBG 4)
- Product category
- SmartWire-DT accessories
- Number of insertion cycles
- 200
- Type of electrical accessory/spare part
- Plug
- Accessory
- Yes
- Spare part
- No
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015081192090
- SAP 1000288913
- Code 8297409
Product Documentation
Document preview: Over.m Darw fl/r.kab via kont (SWD4-SFL8-20) — Specification Data Sheet (OEM)
