Eaton NZM2/3-XAHIV24AC/DC-PI
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton NZM2/3-XAHIV24AC/DC-PI is listed under Electrical Components / Circuit Breaker Accessories. Sales unit: pcs; Eaton catalogue number: 189811; Depth: 115 mm; Height: 65 mm; Width: 75 mm; Weight: 0.08 kg.
Technical Specifications
- Manufacturer part number (MPN)
- NZM2/3-XAHIV24AC/DC-PI
- EAN / GTIN
- 4015081878062
- Sales unit
- pcs
- Eaton catalogue number
- 189811
- Depth
- 115 mm
- Height
- 65 mm
- Width
- 75 mm
- Weight
- 0.08 kg
- Compliances
- UL/CSA; IEC; RoHS conform
- Fitted with
- Early-make auxiliary contact
- Frame
- NZM2/3
- Suitable for
- Motor safety switch; Off-load switch
- Type
- Accessory Shunt release
- Used with
- NZM2(-4), N(S)2(-4); NZM3(-4), N(S)3(-4)
- Electric connection type
- Screw connection
- Rated control supply voltage
- 24 V AC/DC
- Rated control supply voltage (Us) at AC, 50 Hz - max
- 24 V
- Rated control supply voltage (Us) at AC, 50 Hz - min
- 24 V
- Rated control supply voltage (Us) at AC, 60 Hz - max
- 24 V
- Rated control supply voltage (Us) at AC, 60 Hz - min
- 24 V
- Rated control supply voltage (Us) at DC - max
- 24 V
- Rated control supply voltage (Us) at DC - min
- 24 V
- Voltage type
- AC
- Connection type
- With push in terminal
- Number of contacts (change-over contacts)
- 0
- Number of contacts (normally closed contacts)
- 0
- Number of contacts (normally open contacts)
- 1
- Suitable for off-load switch
- Yes
- Suitable for overload relay
- No
- Type of electric connection
- Screw connection
- Rated control supply voltage AC 50 Hz
- 24 V
- Rated control supply voltage AC 60 Hz
- 24 V
- Rated control supply voltage DC
- 24 V
- Suitable for motor safety switch
- Yes
- Suitable for power circuit breaker
- No
- Voltage type for actuating
- AC
- Number of contacts as normally open contact
- 1
- Country of origin
- Romania
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015081878062
- SAP 1200600671
- Code 82989225
