Eaton NZM3-XBSM-TAZ

Eaton NZM3-XBSM-TAZ is listed under Electrical Components / Circuit Breaker Accessories. Sales unit: pcs; Eaton catalogue number: 189833; Depth: 75 mm; Height: 65 mm; Width: 68 mm; Weight: 0.021 kg.

Manufacturer part number (MPN)

NZM3-XBSM-TAZ

EAN / GTIN

4015081878284

Sales unit

pcs

Eaton catalogue number

189833

Depth

75 mm

Height

65 mm

Width

68 mm

Weight

0.021 kg

Compliances

UL/CSA; IEC; RoHS conform

Accessory/spare part type

Communication and measuring function; Interface module; Accessory

Frame

NZM3

Type

Interface module

Used with

NZM3(-4)-PX…-TAZ

Overload proof of digital semi-conductor outputs

Yes (Connection for maintenance mode (ARMS))

Control voltage tolerance

+/- 20%

Current consumption - max

100 mA

Output voltage

3.3 V DC (connection for maintenance mode (ARMS), digital output)

Voltage rating

24 V DC

Degree of protection

Installation in the switch

Number of maintenance connections

1

Strip length

5 mm (supply connection), 6 mm (digital input), 6 mm (relay output)

Terminal capacity (solid cable)

0.2 mm² - 0.5 mm² (1x) at logical zone selectivity (ZSI) connection; 0.2 mm² - 0.5 mm² (1x) at relay outputs of supply connection; 0.2 mm² - 1.5 mm² (1x) at supply connection

Tightening torque

≥ 0.22 Nm; ≤ 0.25 Nm

Type of accessory/spare part

Communication and measuring function

Accessory

Yes

Spare part

No

Country of origin

Romania

HS Code

8538.90

• EAN 4015081878284
• SAP 1200600981
• Code 82989372
