Eaton NZM3-XPS24DC

Eaton NZM3-XPS24DC is listed under Electrical Components / Circuit Breaker Accessories. Sales unit: pcs; Eaton catalogue number: 189823; Depth: 50 mm; Height: 22 mm; Width: 35 mm; Weight: 0.021 kg.

Manufacturer part number (MPN)

NZM3-XPS24DC

EAN / GTIN

4015081878185

Sales unit

pcs

Eaton catalogue number

189823

Depth

50 mm

Height

22 mm

Width

35 mm

Weight

0.021 kg

Compliances

UL/CSA; IEC; RoHS conform

Accessory/spare part type

Other; Power supply module; Accessory

Frame

NZM3

Special features

24 V DC supply to the electronic trip. Mechanical pass-through of the switch's status (I, O) for use by the remote operator.

Type

Power supply module

Used with

NZM3(-4)-VX(MX)…

Control voltage tolerance

+/- 20%

Current consumption - max

100 mA

Voltage rating

24 V DC

Connection type

Screw terminal (supply connection, rated control voltage); With bolt connection; With push in terminal

Degree of protection

Installation in the switch

Strip length

5 mm (supply connection)

Terminal capacity (solid cable)

0.2 mm² - 1.5 mm² (1x) at supply connection

Terminal capacity (stranded cable)

0.2 mm² - 1.5 mm² (1x) at supply connection; 0.25 mm² - 0.75 mm² (1x) at supply connection (uninsulated ferrule according to DIN46224 / 1); 24 - 16 AWG (1x) at supply connection; 0.25 mm² - 0.75 mm² (1x) at supply connection (insulated ferrule according to DIN46224 / 4)

Tightening torque

≤ 0.25 Nm; ≥ 0.22 Nm

Type of accessory/spare part

Communication and measuring function

Accessory

Yes

Spare part

No

Country of origin

Romania

HS Code

8536.20
