Eaton NZM1-XU24DC

Eaton NZM1-XU24DC is listed under Electrical Components / Circuit Breaker Accessories. HS code: 8538.90.

Manufacturer part number (MPN)

NZM1-XU24DC EAN / GTIN: 4015082594527 Sales unit: pcs Eaton catalogue number: 259452 Depth: 37 mm Height: 66 mm Width: 32 mm Weight: 0.073 kg Compliances: UL/CSA; IEC; RoHS conform Certifications: IEC60947; CSA-C22.2 No. 5-09; CSA (File No. 22086); CE marking; CSA (Class No. 1437-01); UL listed; UL (File No. E140305); UL (Category Control Number DIHS); CSA certified; UL489 Frame: NZM1 Suitable for: Off-load switch Type: Accessory Undervoltage release Used with: NZM1(-4), N(S)1(-4) Drop-out voltage of undervoltage release AC/DC - max: 0.7 x Us Drop-out voltage of undervoltage release AC/DC - min: 0.35 x Us Electric connection type: Screw connection minimum command time - max: 15 ms minimum command time - min: 10 ms Pick-up power consumption at AC (undervoltage release): 1.5 VA Pick-up power consumption at DC (undervoltage release): 0.8 W Power consumption: 0.8 W (DC); 1.5 VA (AC) Rated control supply voltage: 24 V DC Rated control supply voltage (Us) at DC - max: 24 V Rated control supply voltage (Us) at DC - min: 24 V Rated control voltage (relay contacts): 24 V DC Reaction time: 19 ms Voltage tolerance - max: 1.1 Voltage tolerance - min: 0.85 Voltage type: DC Connection type: With terminal block on the left-hand switch side Number of contacts (change-over contacts): 0 Number of contacts (normally closed contacts): 0 Number of contacts (normally open contacts): 0 Delayed: No Suitable for off-load switch: Yes Suitable for overload relay: No Type of electric connection: Screw connection Rated control supply voltage DC: 24 V Suitable for motor safety switch: No Suitable for power circuit breaker: No Voltage type for actuating: AC Country of origin: Romania

HS Code

8538.90

• EAN 4015082594527
• SAP 1000289542
• Code 897525
