Eaton SL4-100-L-RG-24LED Signal Tower Red/Green 24 V

Complete SL4 signal tower with two LED light modules in red and green on a 100 mm tube and standard stacklight base, rated for 24 V AC/DC continuous operation. The luminaire has a 360° radiation angle, IP66 and NEMA 4X/13 ingress protection, and a polycarbonate cap and enclosure for indoor or outdoor machine signalling. Certified to IEC/EN 60947-5-1, UL 508 and CSA C22.2. Eaton catalogue number 171295.

Manufacturer part number (MPN)

SL4-100-L-RG-24LED

EAN / GTIN

4015081678389

Sales unit

pcs

Eaton catalogue number

171295

Depth

72 mm

Height

279 mm

Width

72 mm

Weight

0.209 kg

Certifications

UL report applies to both US and Canada; UL Category Control No.: NKCR; CSA Class No.: NKCR7; CSA-C22.2 No. 94-91; IEC/EN 60947-5-1; CE; UL 508; Certified by UL for use in Canada; UL; UL File No.: E29184; CSA-C22.2 No. 14-10; IEC/EN 60529

Catalog Notes

The value specified for the leakage current shall apply per module.

Ambient operating temperature - max

60 °C

Ambient operating temperature - min

-30 °C

Climatic proofing

Damp heat, cyclic, to IEC 60068-2-30; Damp heat, constant, to IEC 60068-2-78

Leakage current

0.003 A

Rated insulation voltage (Ui)

250 V

Rated operational voltage

24 V AC/DC

Rated operational voltage (Ue) - max

24 V

Rated operational voltage (Ue) - min

24 V

Color

Red; Green

Fitted with

100 mm tube; Foot

Light modules

LED

Number of modules

2

Connection to SmartWire-DT

No

Current consumption

0.022 - 0.033 A, at 24 V AC/DC; The value specified for the current consumption at 24 V AC/DC applies to each module.

Degree of protection

IP66; NEMA 4X, 13

Lifespan, electrical

100,000 h

Light type

Continuous light

Material

Cap: Polycarbonate (PC); Enclosure: Polycarbonate (PC)

Mounting Method

Standard stacklight base

Mounting position

As required

Overvoltage category

III

Pollution degree

3

Product Category

SL signal towers

Radiation angle

360 °

Rated impulse withstand voltage (Uimp)

4000 V AC

Shock resistance

Mechanical, According to IEC/EN 60068-2-27; 15 g, Mechanical, According to IEC/EN 60068-2-27, Sinusoidal shock 11 ms

Type

Complete device

Voltage type

AC/DC

Terminal capacity

0.2 - 1.5 mm², solid or flexible conductor; 0.25 - 0.75 mm², flexible with ferrule with plastic collar; 0.25 - 1.5 mm², solid or flexible with ferrule; 24 - 16 AWG

Outer diameter

43 mm

Loudness

0 dB

Function flashing light

No

Function acoustic

No

Function continuous light

Yes

Rated operating voltage Ue

24 V

Function revolving light

No

Operating voltage AC 50 Hz

21.6–26.4 V

Operating voltage AC 60 Hz

21.6–26.4 V

Operating voltage DC

21.6–26.4 V

Voltage type for actuating

AC/DC

Number of signal tower elements

2

Country of origin

Austria

HS Code

8531.80
