BR.DA1 FS2,3F/3F/230V,0,75kW (DX-BR100-100)
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton BR.DA1 FS2,3F/3F/230V,0,75kW (DX-BR100-100) is listed under Drives & Controllers / Drive Accessories. Sales unit: pcs; Eaton catalogue number: 174241; Depth: 150 mm; Height: 20 mm; Width: 85 mm; Weight: 0.28 kg.
Technical Specifications
- Manufacturer part number (MPN)
- DX-BR100-100
- EAN / GTIN
- 4015081707034
- Sales unit
- pcs
- Eaton catalogue number
- 174241
- Depth
- 150 mm
- Height
- 20 mm
- Width
- 85 mm
- Weight
- 0.28 kg
- Certifications
- C22.2; Certified by UL for use in Canada; UL Category Control No.: NMTR2, NMTR8; UL report applies to both US and Canada; UL; UL File No.: E300273; UL508
- Voltage rating - max
- 1000 V
- Fitted with
- Temperature monitoring switch; Connection cables (approx. 0.5 m)
- Accessory/spare part type
- Breaking resistance
- Degree of protection
- IP00; IP65
- Product Category
- Accessories
- Suitable for
- Branch circuits, (UL/CSA)
- Type
- Wire wound resistor in ceramic potting compound inside aluminum case
- Used with
- DA1; DC1; DG1; DM1
- Type of accessory/spare part
- Breaking resistance
- Accessory
- Yes
- Spare part
- No
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8533.29
Cross References
- EAN 4015081707034
- SAP 1200606738
- Code 82996536
Product Documentation
More from Eaton
Eaton
Eaton IZMX40N3-V32W-1
Eaton
Eaton FAZ-Z40/4 Miniature Circuit Breaker — 4P, Type Z, 40 A, 15 kA
Eaton
Front plate IZMX40W V xVTL H600 B800 xEB
EP-502507
Eaton
Fr.Pl. Sealed H800 B800
BPZ-FP-800/800-BL
Eaton
Cam switch, 3P, 12A (T0-2-15679/EZ)
Eaton
Eaton FAZT-B3/4 Miniature Circuit Breaker — 4P, Type B, 3 A, 25 kA
Eaton
Eaton FAZ-D5/3 Miniature Circuit Breaker — 3P, Type D, 5 A, 15 kA
Eaton
Eaton NZMB1-A100-SVE Molded-Case Circuit Breaker 3-Pole 100A 25KA
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy DX-BR100-100?
- DX-BR100-100 can be ordered from cballast.com as a Eaton catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Eaton product?
- The manufacturer part number is DX-BR100-100.
- What is the HS code for DX-BR100-100?
- The customs tariff (HS) code for DX-BR100-100 is 8533.29.
- Who manufactures DX-BR100-100?
- DX-BR100-100 is a Eaton product in the Drives & Controllers range.
- Is a datasheet available for DX-BR100-100?
- Yes — the DX-BR100-100 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for DX-BR100-100?
- The minimum order quantity is 1.
- Is DX-BR100-100 available?
- Yes — DX-BR100-100 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
