Bottom Plate FOR Flange F3A B1000
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton AFP-10-CS is a bottom plate for 1000 mm wide CS wall-mounted steel enclosures, with two F3A flange apertures. Used with the matching F3A flange plates it maintains the enclosure IP66 rating, and it can serve as a roof plate by turning the enclosure through 180 degrees. RAL7035. EN62283.
Technical Specifications
- Manufacturer part number (MPN)
- AFP-10-CS
- EAN / GTIN
- 4015081124572
- Sales unit
- pcs
- Eaton catalogue number
- 112919
- Depth
- 175 mm
- Height
- 5 mm
- Width
- 1000 mm
- Weight
- 1.2 kg
- Compliances
- RoHS conform
- Functions
- Usable as a roof plate by turning the enclosure through 180°; Not suitable for enclosure CS-…/150
- RAL-number
- 7035
- Special features
- For flange F3A With foamed gasket
- Used with
- Enclosure width = 1000 mm
- Accessory/spare part type
- Bottom plate
- Color
- Light gray (RAL 7035); Gray
- Model
- Floor plate
- Type
- Accessory CS
- Flange apertures
- 3
- Material
- Steel plate; Metal
- Suitable for enclosure building height
- 1200 mm
- Suitable for enclosure building length/depth
- 300 mm
- Suitable for enclosure building width
- 1000 mm
- Surface finishing
- Semi-textured
- Degree of protection
- IP66 (if used properly with F3A-… flanges)
- Colour
- Grey
- Country of origin
- Spain
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015081124572
- SAP 1000704196
- Code 8422601
