Connection Terminal 16-70mm², f 10mm
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton Connection Terminal 16-70mm², f 10mm (part number AKU70/10) is listed under Electrical Components / Terminal Blocks. Sales unit: pcs; Package quantity: 25 pcs; Eaton catalogue number: 107193; Depth: 21 mm; Height: 42 mm; Width: 32 mm.
Technical Specifications
- Manufacturer part number (MPN)
- AKU70/10
- EAN / GTIN
- 4015081069569
- Sales unit
- pcs
- Package quantity
- 25 pcs
- Eaton catalogue number
- 107193
- Depth
- 21 mm
- Height
- 42 mm
- Width
- 32 mm
- Weight
- 0.07 kg
- Compliances
- UL CSA09 (refer to approbation report); RoHS conform
- Certifications
- UL (File No. E307559); UL508A; CE marking; CSA (Class No. 3211-37); UL (Category Control Number NMTR2, NMTR8); IEC 60439-1; North America (UL listed, CSA certified); CSA-C22.2 No. 14; CSA (File No. 236217)
- Functions
- Universal conductor connection terminal; Connections; Current limiting circuit breaker, refer to approbation report
- Special features
- With integrated retaining spring, open terminal chamber and captive terminal screw
- Suitable for
- Round conductor connection; Strip conductor connection; Flat rail; Sector conductor connection
- Used with
- All 10 mm thick flat busbars; Feeder circuits; Connection; 60 mm system; 185 mm system; Compact system
- Type
- 185 mm system 60 mm system Compact system Connection
- Rated operation current (Ie)
- 400 A
- Rated operational current
- 400 A
- Rated operational current (Ie) - max
- 400 A
- Voltage rating (UL CSA 13)
- Max. 600 V AC
- Busbar thickness - max
- 10 mm
- Busbar thickness - min
- 10 mm
- Conductor cross section - max
- 70 mm²
- Degree of protection
- Feeder circuits; UL508A; CSA-C22.2 No. 14; IEC 60439-1; CE marking
- Terminal capacity (conductor)
- 16 mm² - 70 mm²; 3 segments of 9 mm x 0.8 mm (2x); AWG 4 - AWG 2/0; 9 mm x 0.8 mm (6x)
- Terminal contact area
- 14 mm x 14 mm
- Width clamp
- 20.5 mm
- Max. conductor cross section
- 70 mm²
- Busbar thickness
- 10 mm
- Suitable for strip conductor connection
- Yes
- Suitable for round conductor connection
- Yes
- Suitable for sector conductor connection
- Yes
- Max. rated operation current Ie
- 400 A
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4015081069569
- SAP 1200607321
- Code 82995628
Product Documentation
