Eaton XPIXBCB-H-1002 Horizontal Internal Segregation for 2 x IZMX16 Enclosures
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton XPIXBCB-H-1002 horizontal internal-segregation assembly kit for enclosures housing two IZMX16 breakers, suitable for form 4a and 4b separations. Red plastic construction, 860 mm wide by 620 mm deep for a 1000 mm x 600 mm enclosure.
Technical Specifications
- Manufacturer part number (MPN)
- XPIXBCB-H-1002
- EAN / GTIN
- 4015081710195
- Sales unit
- pcs
- Eaton catalogue number
- 174564
- Depth
- 620 mm
- Height
- 40 mm
- Width
- 860 mm
- Weight
- 2.84 kg
- Compliances
- RoHS conform
- RAL-number
- 0
- Suitable for
- Internal separation form 4a; Internal separation form 4b
- Color
- Red
- Construction type
- Assembly kit
- Material
- Plastic
- Modular spacing
- 12.5 mm
- Number of height units
- 0
- Suitable for enclosure building length/depth
- 600 mm
- Suitable for enclosure building width
- 1000 mm
- Surface finishing
- Untreated
- Suitable for enclosure building depth
- 600 mm
- Colour
- Red
- With cable entry
- No
- With lock
- No
- For internal separation form 2a
- No
- For internal separation form 2b
- No
- For internal separation form 3a
- No
- For internal separation form 3b
- No
- For internal separation form 4a
- Yes
- For internal separation form 4b
- Yes
- Country of origin
- Czechia
