Eaton XPIX16CCB-B-08 Vertical Partition 2x IZMX16 Bottom
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton XPIX16CCB-B-08 vertical partition for two IZMX16 devices mounted at the bottom, 65 mm wide by 1268 mm high by 702 mm deep. Powder-coated steel in RAL 7035 grey, 16.39 kg, RoHS conform. Suitable for internal separation forms 2a, 2b, 3a, 3b, 4a and 4b in 800 mm deep enclosures.
Technical Specifications
- Manufacturer part number (MPN)
- XPIX16CCB-B-08
- EAN / GTIN
- 4015081710232
- Sales unit
- pcs
- Eaton catalogue number
- 174568
- Depth
- 702 mm
- Height
- 1268 mm
- Width
- 65 mm
- Weight
- 16.39 kg
- Compliances
- RoHS conform
- RAL-number
- 7035
- Suitable for
- Internal separation form 4a; Internal separation form 4b; Internal separation form 3b; Internal separation form 2a; Internal separation form 2b; Internal separation form 3a
- Color
- Gray
- Construction type
- Individual part
- Material
- Steel
- Modular spacing
- 12.5 mm
- Number of height units
- 0
- Suitable for enclosure building length/depth
- 800 mm
- Suitable for enclosure building width
- 65 mm
- Surface finishing
- Powder coating
- Suitable for enclosure building depth
- 800 mm
- Colour
- Grey
- With cable entry
- No
- With lock
- No
- For internal separation form 2a
- Yes
- For internal separation form 2b
- Yes
- For internal separation form 3a
- Yes
- For internal separation form 3b
- Yes
- For internal separation form 4a
- Yes
- For internal separation form 4b
- Yes
- Country of origin
- Czechia
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4015081710232
- SAP 1200601688
- Code 82988906
Product Documentation
