Eaton FUSE Switch Disconnector (XNH00-S160-BT1)

Eaton XNH00-S160-BT1 NH fuse-switch 3p box terminal 1,5 - 95 mm², busbar 60 mm, NH000 & NH00.

Manufacturer part number (MPN)

XNH00-S160-BT1

EAN / GTIN

4015081779611

HS code

8536.90

Sales unit

pcs

Eaton catalogue number

183034

Depth

204 mm

Height

137 mm

Width

106 mm

Weight

0.811 kg

Compliances

RoHS conform

Certifications

IEC/EN 60947-3

Features

Halogen free; Standard sealable

Flammability characteristics (UL)

Self-extinguishing (UL 94)

Special features

Permanent operation (rated operating mode) Current paths of electrolytic copper, silver-plated Cable connection optionally at the top or bottom

Suitable for

Busbar mounting; Front mounting

Actuator type

Cover grip

Color

Gray

Number of poles

Three-pole

Type

Basic device

Ambient operating temperature details

Ambient temperature range: -25 °C - 70 °C

Equipment heat dissipation, current-dependent

14 W

Heat deflection temperature

125 °C

Heat dissipation at 80% without fuses

9 W

Heat dissipation per pole, current-dependent

4.7 W

Rated operational current for specified heat dissipation (In)

160 A

Total heat dissipation without fuses at Ith

14 W

Creepage resistance

CTI 600

Direction of incoming supply

As required (FLEX System)

Electrical connection type of main circuit

Frame clamp

Frequency rating

40 Hz - 60 Hz

Frequency rating of contacts

40 Hz - 60 Hz

Lifespan, electrical

300 operations

Operating altitude without derating - max

2000 mm

Overvoltage category

III

Permitted power loss per fuse link - max

12 W

Pollution degree

3

Power rating at AC-23, 400 V

0 kW

Rated conditional short-circuit rating

100 kA (690 V); 120 kA (500 V)

Rated impulse withstand voltage (Uimp)

8 kV

Rated insulation voltage (Ui)

800 VAC

Rated operating voltage (Ue) at AC - max

690 V

Rated operation current (Ie)

160 A

Rated operational current

160 A (AC-22B); 160 A; 160 A (AC-23B); 160 A (AC-21B)

Rated short-time withstand current (Icw)

7 kA

Rated uninterrupted current (Iu)

160 A

Voltage rating at AC

400 V (AC-23B) 500 V (AC-22B) 690 V (AC-21B)

Voltage rating at DC

250 V DC at DC-22B 440 V DC at DC-21B

Voltage test

Yes, sliding inspection windows

Conditioned rated short-circuit current Iq

120 kA

Rated conditional short-circuit current (Iq)

120 kA

Activation type

Dependent manual activation

Actuator position

Front side

Cable entry type

Other

Degree of protection (front side)

Other

Lifespan, mechanical

1400 operations

Locking facility

Yes, optional

Material

Polyamide

Mounting method

Busbars of 60 mm

Mounting position

Vertical or horizontal

Size

NH000 / NH00 fuse

Suitable for fuses

NH00

Terminal capacity (copper band)

9 mm x 0.8 mm (6x) at box terminal

Terminal capacity (copper busbar)

Bolt diameter at flange connection: M8; Max. 25 mm cable lug width at flange connection; 20 mm x 10 mm

Terminal capacity (copper strip)

9 mm x 0.8 mm (9x) at box terminal

Terminal capacity (stranded cable)

1.5 mm² - 50 mm² at box terminal; 1.5 mm² - 95 mm² at box terminal; 10 mm² - 70 mm² at clamp-type terminal

Connection type

Box terminal

Degree of protection

IP2XC (contact protection, XNH installed); IP10 (handle cover open, XNH installed); IP20 (operating status, XNH installed)

HS Code

8536.90
