Eaton PLHT-OV80/4 Miniature Circuit Breaker — 4P, OV, 80 A, 20 kA

Eaton PLHT-OV80/4 miniature circuit breaker (MCB) from the xPole PLHT range. 4-pole, rated current In = 80 A, thermomagnetic overload and short-circuit release (Eaton 'OV' overload-protection designation). Rated ultimate short-circuit breaking capacity Icu = 20 kA to IEC/EN 60947-2; rated operational voltage Ue 230/400 V AC. DIN-rail (35 mm) modular device for overload and short-circuit protection of cables and equipment. Conforms to IEC/EN 60947-2. Eaton type PLHT-OV80/4, EAN 4015082649913, Eaton/SAP material 1000068791, catalogue code 8557830.

Manufacturer

Eaton

Product family

xPole PLHT

Type designation

PLHT-OV80/4

Manufacturer part number (MPN)

PLHT-OV80/4

EAN / GTIN

4015082649913

Eaton / SAP material no.

1000068791

Poles

4P

Release

thermomagnetic (overload + short-circuit)

Rated current In

80 A

Rated ultimate breaking capacity Icu

20 kA

Rated operational voltage Ue

230/400 V AC

Mounting

DIN rail (35 mm)

Standard

IEC/EN 60947-2

HS code

8536.20

Sales unit

pcs

Eaton catalogue number

264991

Depth

90 mm

Height

75 mm

Width

108 mm

Weight

0.919 kg

Compliances

RoHS conform

Current limiting class

3

Features

Additional equipment possible

Special features

Ambient temperature hint: a 1 °C increase results in a 0.35% linear reduction of current carrying capacity

Amperage Rating

80 A

Number of poles (protected)

4

Number of poles (total)

4

Release characteristic

Other

Ambient operating temperature - max

55 °C

Ambient operating temperature - min

-25 °C

Equipment heat dissipation, current-dependent

28.4 W

Heat dissipation capacity

0 W

Heat dissipation per pole, current-dependent

7.1 W

Rated operational current for specified heat dissipation (In)

80 A

Static heat dissipation, non-current-dependent

0 W

Frequency rating - max

60 Hz

Frequency rating - min

50 Hz

Overvoltage category

III

Pollution degree

2

Rated impulse withstand voltage (Uimp)

4 kV

Rated insulation voltage (Ui)

440 V

Rated operational voltage (Ue) - max

400 V

Rated short-circuit breaking capacity (IEC 60947-2)- Icu at 230 V

20 kA

Rated short-circuit breaking capacity (IEC 60947-2)- Icu at 400 V

20 kA

Voltage type

AC

Built-in depth

75 mm

Connectable conductor cross section (multi-wired) - max

50 mm²

Connectable conductor cross section (multi-wired) - min

2.5 mm²

Connectable conductor cross section (solid-core) - max

50 mm²

Connectable conductor cross section (solid-core) - min

2.5 mm²

Degree of protection

IP20

Width in number of modular spacings

4

Standard

IEC/EN 60947-2

HS Code

8536.20

• EAN 4015082649913
• SAP 1000068791
• Code 8557830
