DIN 2353 Compression Elbow 10mm Tube
Swagelok · Pipes, Fittings & Flanges · Compression Fittings
Swagelok SS-10M0-9, catalog identifier for the specific configuration. DIN 2353 compression elbow fitting for 10mm OD tube. Zinc-plated carbon steel body with cutting ring. Supplied for general industrial and marine service under the applicable OEM specification. Manufacturer: Swagelok. Manufacturer part number: SS-10M0-9. Available on quote-to-invoice terms via cBallast. Lead time and freight are quoted per RFQ against destination Incoterm.
Specifications
- Part number
- SS-10M0-9
- HS code
- 7307.19
- Material
- Carbon Steel, Zinc Plated
- Pressure rating
- 400 bar (L-series)
- Temperature range
- -20°C to +200°C
- Standard
- DIN 2353 / ISO 8434-1
- Standard size
- 10mm
- Thread standard
- Metric Compression
Compatibility
Swagelok 316 SS tube fitting union elbow, 10 mm OD tube both ends. Gaugeable two-ferrule design; fits 10 mm OD metric tubing (equivalent service to DIN 2353 10L installations).
Standards
- ISO 9001
- NACE MR0175/ISO
- ASME B31.3
- DIN 2353
- ISO 8434-1
Approvals
