Product Description
Cimco 132300 is a complete round punch and die set for M16 / Ø16.2 mm holes in steel sheet up to 2.0 mm (ST 37), supplied with a 9.5 x 50 mm draw bolt for hydraulic or mechanical actuation. A pre-drilled Ø10.0 mm pilot hole is required to seat the draw bolt through the workpiece. Typical applications include gland and cable-entry holes in switchgear cabinets, junction boxes, and machine enclosures.
Technical Specifications
- Manufacturer part number (MPN)
- 132300
- EAN / GTIN
- 4021103323007
- Sales unit
- pcs
- Model
- Matrix and punch
- Hole diameter
- 16.2 mm
- Punch shape
- Round
- Material to process
- Steel
- Hydraulic operation
- Yes
- Mechanical operation
- Yes
- Slit punch
- Yes
- Hole width
- 16.2 mm
- Hole height
- 2 mm
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8207.30
Cross References
- EAN 4021103323007
- SAP 1000629376
- Code 8135866
Product Documentation
Document preview: Cimco 132300 Round Punch and Die Set M16 / Ø16.2 mm for Steel Sheet — Specification sheet
More from Cimco
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 132300?
- 132300 can be ordered from cballast.com as a Cimco catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Cimco product?
- The manufacturer part number is 132300.
- What is the HS code for 132300?
- The customs tariff (HS) code for 132300 is 8207.30.
- Who manufactures 132300?
- 132300 is a Cimco product in the Tools range.
- Is a datasheet available for 132300?
- Yes — the 132300 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 132300?
- The minimum order quantity is 1.
- Is 132300 available?
- Yes — 132300 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
