Carlo Gavazzi ESY3XAV5 EMS 3-Phase Current Measurement Module 5 A CT
Pricing
Request a quote
We reply within 24 hours
Product Description
Carlo Gavazzi ESY3XAV5 is a three-phase current measurement accessory for the EMS energy monitoring system, compatible with 5 A secondary current transformers on three-conductor or four-conductor loads. The module is self-powered, communicates over RS485 Modbus RTU and provides a static pulse output. DIN-rail mount, 1 module wide (18 mm), 90 x 44 mm. Country of origin Italy.
Technical Specifications
- Manufacturer part number (MPN)
- ESY3XAV5
- EAN / GTIN
- 8054155008956
- Sales unit
- pcs
- Frequency
- 50Hz; 60Hz
- Current inputs
- 5 A current transformers
- Energy metering
- Consumption and generation
- Static output
- Pulse
- Communication port and protocol
- RS485 (Modbus RTU)
- Power supply
- Self power supply
- E-number (NO)
- 8200760
- E-number (SE)
- 0981090
- Mounting method
- DRA (DIN-rail adaptor)
- Width
- 18 mm
- Model
- Measurement transformer
- Height
- 90 mm
- Depth
- 44 mm
- Suitable for
- Purchase/supply
- Max. current (Imax)
- 5 A
- Width in number of modular spacings
- 1
- Type of meter
- Electronic
- Energy type
- Effective power and reactive power
- Tariff type
- Two-tariff
- Tariff control
- Internal/external
- Escapement mechanism
- No
- Calibrated
- Yes
- Pole type
- Three conductor/four conductor
- Measurement type load profile
- No
- Nominal current (In)
- 5 A
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 9028.30
Cross References
- EAN 8054155008956
- SAP 1200966337
- Code 84275742
