Bio-UV Triogen UV CF 105 Medium-Pressure UV Disinfection System

Triogen UV CF 105 medium-pressure ultraviolet disinfection system for commercial pools, spas and water features. Rated flow 105 m3/h (462 US gpm) at a UV dose of 60 mJ/cm2 and 157 m3/h (691 US gpm) at 40 mJ/cm2, both at 95% UVT and end of 8,000-hour lamp life. Single 2.0 kW medium-pressure polychromatic lamp, electropolished 316L stainless reactor vessel rated 10 bar(g), Smartdrive automatic wiper with UV monitor, wall-mounted touchscreen control panel. CE marked, UL listed, NSF50 certified; manufactured to ISO 9001:2015.

Model

CF 105

Flow @60 mJ/cm2 (95% UVT, end of lamp life)

105 m3/h (462 US gpm)

Flow @40 mJ/cm2 (95% UVT, end of lamp life)

157 m3/h (691 US gpm)

Lamp

1 x medium-pressure polychromatic, 2.0 kW, 8,000 h

Reactor vessel

electropolished 316L stainless steel, 10 bar(g)

Lamp / thimble

high-purity quartz

Flanges

BS EN1092 PN10, ANSI 150 or COMBI (confirm DN at order)

Control panel

wall-mounted touchscreen microprocessor, polyester-coated mild steel, IP54

Wiper

Smartdrive automatic, with UV monitor

Comms

data logging, BMS, Modbus, Ethernet

Supply

220/1/60 or 230/1/50 (options 380-480 V 3-ph; confirm at order)

Certification

CE marked, UL listed, NSF50 certified (options available); ISO 9001:2015

Standard

ISO 9001:2015

Size / Series

CF 105

Material

Electropolished 316L stainless steel reactor vessel (rated 10 bar(g)); high-purity quartz lamp and thimble; polyester-coated mild steel control panel (IP54)

Thread Standard

Flanged BS EN1092 PN10, ANSI 150 or COMBI

Pressure Rating

10 bar(g) (reactor vessel)

IP Rating

IP54 (control panel)

Classification / Approval

CE

HS Code

8421.21
