Ball Valve SS316 2-Piece Full Bore BSP 3/4"
Generic · Valves · Ball Valves
Stainless steel 316 two-piece full bore ball valve with BSP female threads. PTFE seats and seals. Lockable lever handle.
Specifications
- Part number
- BV316-FB-3-4
- HS code
- 8481.80
- Material
- SS316 (CF8M)
- Pressure rating
- 1000 WOG (68 bar)
- Temperature range
- -20°C to +200°C
- Standard
- ISO 7/1 BSP
- Standard size
- 3/4"
Compatibility
Interchanges with Swagelok 60 Series 3-piece ball valve family (SS-6*TF*RT), but Swagelok does not list a 3/4 in. BSPT female variant in 316 SS; item is available from other OEMs only.
Standards
- ISO 9001
- NACE MR0175/ISO
- ASME B16.34
- API 607
- ISO 5208
- EN 12266-1
Approvals
