Ball Valve SS316 2-Piece Full Bore BSP 1"
Pricing
Request a quote
We reply within 24 hours
Product Description
Swagelok SS-65TF16RT Stainless steel 316 two-piece full bore ball valve with BSP female threads. PTFE seats and seals. Lockable lever handle. Deployed in process, utility and marine piping loops for on-off shutoff, control, safety relief or diversion service.
Technical Specifications
- material
- SS316 (CF8M) Standard: ISO 7/1 BSP Standard size: 1" Pressure rating: 1000 WOG (68 bar) Temperature range: -20°C to +200°C Approval: ISO 9001, PED 2014/68/EU, NACE MR0175/ISO 15156, ASME B16.34 (select), API 607 (FE variants) Standards: ISO 9001, NACE MR0175/ISO, ASME B16.34, API 607 Approvals: PED, NACE MR0175 HS code: 8481.80
Standards & Compliance
- Standard
- ISO 7/1 BSP
- Size / Series
- 1"
- Material
- SS316 (CF8M)
- Pressure Rating
- 1000 WOG (68 bar)
- Temperature Range
- -20°C to +200°C
- Classification / Approval
- ISO 9001, PED 2014/68/EU, NACE MR0175/ISO 15156, ASME B16.34 (select), API 607 (FE variants)
- HS Code
- 8481.80
Compatibility & Fitment
Swagelok 60 Series 3-piece ball valve, 316 SS body, 1 in. ISO tapered (BSPT) female both ends, reinforced PTFE seats. 60 Series 3-piece, 1500 psig @ 100 degF.
