ABB MO165-16 manual motor starter magnetic only 16 A

ABB MO165-16 manual motor starter magnetic only (motor protector), order code 1SAM461000R1011. Rated operational current 16 A; rated motor power 7.5 kW at 400 V AC (AC-3). Three-pole fuseless device with an electromagnetic (instantaneous) short-circuit release only — it has no thermal overload release, so it is combined with a separate overload relay or motor controller for full motor protection. Rated instantaneous short-circuit release setting Ii 240 A; rated service short-circuit breaking capacity Ics 100 kA at 400 V AC. Built-in disconnect function, trip-free mechanism, ON/OFF/TRIP indication and lockable rotary handle. Rated operational voltage up to 690 V AC, IP20, 55 mm width, DIN-rail or screw mounting. Part of the ABB MS116/MS132/MS165/MO132/MO165 manual-motor-starter range. Supplied as OEM original where available, or a verified compatible equivalent.

Type

ABB MO165-16

Order code

1SAM461000R1011

Rated uninterrupted current Iu

16 A

Rated operational current Ie

16 A

Rated motor power at 400 V AC (AC-3)

7.5 kW

Construction

3-pole, electromagnetic short-circuit release only (magnetic only), fuseless

Overload protection

none — combine with an overload relay or motor controller

Rated instantaneous short-circuit release setting Ii

240 A

Rated service short-circuit breaking capacity Ics at 400 V AC

100 kA

Functions

disconnect function, trip-free mechanism, ON/OFF/TRIP indication, lockable rotary handle

Rated operational voltage Ue

up to 690 V AC

Rated insulation voltage Ui

690 V

Rated impulse withstand voltage Uimp

6 kV

Rated frequency

50/60 Hz

Degree of protection

IP20

Width

55 mm; DIN-rail or screw mounting

Accessories

auxiliary contacts, signaling contacts, undervoltage releases, shunt trips, 3-phase busbars, power in-feed blocks

Standards

IEC/EN 60947-1, IEC/EN 60947-2, IEC/EN 60947-4-1, UL 508

IP Rating

IP20

Classification / Approval

CE, cULus (UL 508)

HS Code

8536.20
