Auxiliary contact CA 5-04N 4NC

ABB 1SBN010040R1204 — CA5-04N is a 4-pole front mounted auxiliary contact block equipped with screw terminals. CA5-.N version offers terminal assortment matching the marking of 4-pole N serie contactor relays. CA5-04N is available with 0 N.O. and 4 N.C. instantaneous contacts for standard industrial environments.

Manufacturer part number (MPN)

1SBN010040R1204 EAN / GTIN: 3471522121196 Sales unit: pcs Contact configuration: 4 NC Configuration Only: No Country of Origin: Czechia Criticality: No Lead Time: 25 day Note: No Product Availability Class: From stock if available, otherwise Target delivery time is Product Sales Status: Active Storage Location: 4001 Technical Information: For ACS5000, the 1SBN010040R1204 is replaced by 3ABD00037450 CA4-04N auxiliary contact, and contactor 2UBA015159R0001 NFZ40E-21 has to be purchased the same time. Product Net Width: 43 mm Product Net Depth / Length: 39 mm Product Net Height: 47 mm Number of Auxiliary Contacts NO: 0 Number of Auxiliary Contacts NC: 4 Number of Poles: 4P Rated Operational Voltage: Auxiliary Circuit 690 V Rated Frequency (f): Auxiliary Circuit 50 / 60 Hz Rated Operational Current AC-15 (I e ): (500 V) 2 A; (690 V) 2 A; (24 / 127 V) 6 A; (220 / 240 V) 4 A; (380 / 400 V) 3 A Rated Operational Current DC-13 (I e ): (24 V) 6 A / 144 W; (48 V) 2.8 A / 134 W; (72 V) 1 A / 72 W; (110 V) 0.55 A / 60 W; (125 V) 0.55 A / 69 W; (220 V) 0.30 A / 66 W; (250 V) 0.3 / 75 W Short-Circuit Protective Devices: Auxiliary Circuit - gG Type Fuses 10 A Rated Short-time Withstand Current Low Voltage (I cw ): for 0.1 s 140 A; for 1 s 100 A Rated Insulation Voltage (U i ): acc. to IEC 60947-5-1 690 V; acc. to UL/CSA 600 V Maximum Electrical Switching Frequency: 1200 cycles per hour Mechanical Durability: 10 million Maximum Mechanical Switching Frequency: 3600 cycles per hour minimum Switching Capacity: N 17 / 5 VLT4K Power Loss: at Rated Operating Conditions per Pole 0.1 W Degree of Protection: acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20 Terminal Type: Screw Terminals Suitable For: N22E; N31E; N40E; NL22E; NL31E; NL40E; TNL22E; TNL31E; TNL40E Remarks: 100 CB Certificate: CB_SE_62119A1 CCC Certificate: CCC_2015010304800518 CQC Certificate: CQC2015010304800518; CQC2004010305133985 Declaration of Conformity - CCC: 2020980304001627; 2020980305001185 Declaration of Conformity - CE: 1SBD250809U1000 Declaration of Conformity - UKCA: 1SBD250826U1000 DNV GL Certificate: DNV_GL_TAE00001UT RINA Certificate: RINA_ELE172319XG001 Object Classification Code: K ETIM 7: EC000041 - Auxiliary contact block eClass: V11.0 : 27371302 UNSPSC: 39121522 IDEA Granular Category Code (IGCC): 4743 >> Auxiliary contact block

HS Code

8538.90

• EAN 3471522121196
• SAP 1000039325
• Code 8739576
