Modular LOAD-Break SWITCH, E203/100R
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 2CDE283001R0100 — These devices are suitable for commanding loads and they are realized according EN 60947-3 and EN 60669-1 respectively. Fast removal without dismantling of the busbar. Captive screws with recessed/slotted head. Pozidrive size 2. Add-on of up to 3 auxiliary contact S2C-H6R possible Integrated lay-on edge for labeling system ILS. Locking device as accessories for unauthorized ON/OFF. Approval: VDE, CCC, KEMA.
Technical Specifications
- Manufacturer part number (MPN)
- 2CDE283001R0100 EAN / GTIN: 4016779646123 HS code: 8536.90 Sales unit: pcs Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 81.9 % ABB Site Meeting Group Waste To Landfill Target: No non-hazardous waste is sent to a landfill Extended Product Lifetime: Product Durability End Of Life Disassembling Instructions: 9AKK108469A1170 Environmental Product Declaration - EPD: 9AKK108471A4712 Rated Service Short-Circuit Breaking Capacity (I cs ): 25 kA Number of Poles: 3P Switch Type: Off Recommended Screw Driver: Pozidriv 2 Accessories Available: Yes Cover Color: Grey Installation Size: acc. to DIN 43880 3 Rated Voltage (U r ): 400 V; 12 V minimum Rated Operational Voltage: 230 / 400 V AC Voltage Protection Level ( Up): 4 kV Input Voltage Type: AC Rated Current (I n ): 100 A Rated Short-Circuit Capacity: (230 / 400 V AC) 25 kA Rated Conditional Short-Circuit Current (I nc ): 25 kA Rated Frequency (f): 50/60 Hz Power Loss: at Rated Operating Conditions per Pole 3.95 W Number of Contacts CO: 0 Number of Contacts NC: 0 Number of Contacts NO: 3 Overvoltage Category: IV Degree of Protection: IP10 Pollution Degree: 3 Width in Number of Modular Spacings: 3 Product Net Width: 52.5 mm Product Net Height: 85 mm Product Net Depth / Length: 69 mm Built-In Depth ( t 2 ): 70 mm Declaration of Conformity - CE: 2CDK441011D0403 Instructions and Manuals: 2CSC400002D0208 Mounting Type: DIN-Rail ETIM 9: EC001047 - Selective main line circuit breaker UNSPSC: 39122233 eClass: V11.0 : 27142301 IDEA Granular Category Code (IGCC): 5293 >> Switch disconnector Object Classification Code: Q Standards: IEC/EN 60947-3 Certification Agency: EN; IEC
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4016779646123
- SAP 1000029455
- Code 8268567
Product Documentation
More from ABB Automasjon
ABB Automasjon
Circuit Breaker S203M-C 50
2CDS273001R0504
ABB Automasjon
Circuit Breaker S203M-C 4
2CDS273001R0044
ABB Automasjon
Circuit Breaker S202M-C 32
S202M-C32
ABB Automasjon
Residual Current Circuit Breaker F204 A-25/0,03
2CSF204101R1250
ABB Automasjon
Logic Plinth CR-M4LS
ABB Automasjon
SK 616013-F (MCBH-00)
ABB Automasjon
Terminal Cover LONG OTS400G1L/3
ABB Automasjon
Document pocket A4 SELF-ADHESIVE.ZA13
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 2CDE283001R0100?
- 2CDE283001R0100 can be ordered from cballast.com as a ABB Automasjon catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB Automasjon product?
- The manufacturer part number is 2CDE283001R0100.
- What is the HS code for 2CDE283001R0100?
- The customs tariff (HS) code for 2CDE283001R0100 is 8536.90.
- Who manufactures 2CDE283001R0100?
- 2CDE283001R0100 is a ABB Automasjon product in the Switchgear & Protection range.
- Is a datasheet available for 2CDE283001R0100?
- Yes — the 2CDE283001R0100 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 2CDE283001R0100?
- The minimum order quantity is 1.
- Is 2CDE283001R0100 available?
- Yes — 2CDE283001R0100 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
