Modular LOAD-Break SWITCH,E202/125R

ABB 2CDE282001R0125 — These devices are suitable for commanding loads and they are realized according EN 60947-3 and EN 60669-1 respectively. Fast removal without dismantling of the busbar. Captive screws with recessed/slotted head. Pozidrive size 2. Add-on of up to 3 auxiliary contact S2C-H6R possible Integrated lay-on edge for labeling system ILS. Locking device as accessories for unauthorized ON/OFF. Approval: VDE, CCC, KEMA.

Manufacturer part number (MPN)

2CDE282001R0125 EAN / GTIN: 4016779645966 HS code: 8536.90 Sales unit: pcs Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 81.9 % ABB Site Meeting Group Waste To Landfill Target: No non-hazardous waste is sent to a landfill Extended Product Lifetime: Product Durability End Of Life Disassembling Instructions: 9AKK108469A1170 Environmental Product Declaration - EPD: 9AKK108471A4712 Rated Service Short-Circuit Breaking Capacity (I cs ): 25 kA Number of Poles: 2P Screw Terminal Type: Cage Terminal Switch Type: Off Actuator Marking: I / O Actuator material: Insulation Group II, Black, Sealable Recommended Screw Driver: Pozidriv 2 Accessories Available: Yes Cover Color: Grey Installation Size: acc. to DIN 43880 3 Wire Stripping Length: 12 mm Terminal Type: Screw Terminals Actuator Type: Toggle Rated Voltage (U r ): 400 V; 12 V minimum Rated Operational Voltage: 230 / 400 V AC Voltage Protection Level ( Up): 4 kV Input Voltage Type: AC Rated Current (I n ): 125 A Rated Short-Circuit Capacity: (230 / 400 V AC) 25 kA Rated Conditional Short-Circuit Current (I nc ): 6 kA Rated Frequency (f): 50/60 Hz Power Loss: at Rated Operating Conditions per Pole 6.1 W Number of Contacts CO: 0 Number of Contacts NC: 0 Number of Contacts NO: 2 Overvoltage Category: IV Ambient Air Temperature: Operation -25 ... +55 °C; Storage -40 ... +70 °C Degree of Protection: IP10 Pollution Degree: 3 Width in Number of Modular Spacings: 2 Product Net Width: 35 mm Product Net Height: 85 mm Product Net Depth / Length: 69 mm Built-In Depth ( t 2 ): 70 mm Declaration of Conformity - CE: 2CDK441011D0403 Instructions and Manuals: 2CSC400002D0208 Mounting Type: DIN-Rail ETIM 9: EC001047 - Selective main line circuit breaker UNSPSC: 39122233 eClass: V11.0 : 27142301 Standards: IEC/EN 60947-3 Certification Agency: EN; IEC

HS Code

8536.90

• EAN 4016779645966
• SAP 1000010291
• Code 880770
