ABB SACE Tmax XT7H 1000 Moulded-Case Circuit Breaker — Ekip Hi-Touch LSI 1000A, In=1000 A, 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT7H 1000 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 1000 A, 4-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip Hi-Touch LSI 1000A (L overload, S short-time-delay, I instantaneous protection). Breaking-capacity class H; rated ultimate short-circuit breaking capacity Icu = 70 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA101199R1, EAN 8056221015028, ABB/SAP material 1200638857, catalogue code 83052519.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT7 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT7H 1000 Ekip Hi-Touch LSI 1000A 4p FF
- ABB order code (MPN)
- 1SDA101199R1
- EAN / GTIN
- 8056221015028
- ABB / SAP material no.
- 1200638857
- Frame
- XT7 (1000 A frame)
- Breaking-capacity class
- H
- Rated ultimate breaking capacity Icu (415 V AC)
- 70 kA
- Trip unit
- Ekip Hi-Touch LSI 1000A
- Rated uninterrupted current In
- 1000 A
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221015028
- SAP 1200638857
- Code 83052519
Product Documentation
More from ABB
ABB
AUX-C 1Q+1SY 400VAC XT2-XT4 W
1SDA066445R1
ABB
ABB SACE Tmax XT2V 160 Moulded-Case Circuit Breaker — TMD 32-320, In=32 A, 4-Pole
1SDA067706R1
ABB
ABB S201M-D20 Miniature Circuit Breaker — 1P+N, Type D, 20 A, 10 kA
2CDS271103R0201
ABB
Ekip G-LS/In In=250A XT4 4P
1SDA068047R1
ABB
ABB S203M-D2 Miniature Circuit Breaker — 3P, Type D, 2 A, 10 kA 2CDS273001R0021
ABB
Ekip LS/In In=250A XT4 4P
1SDA067522R1
ABB
ABB CT8/1200 Feed-Through Current Transformer 1200/5 A Class 0.5
2CSG521200R1101
ABB
ZW367 WR-rail L=150mm
2CPX041850R9999
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA101199R1?
- 1SDA101199R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA101199R1.
- What is the HS code for 1SDA101199R1?
- The customs tariff (HS) code for 1SDA101199R1 is 8536.20.
- Who manufactures 1SDA101199R1?
- 1SDA101199R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA101199R1?
- Yes — the 1SDA101199R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA101199R1?
- The minimum order quantity is 1.
- Is 1SDA101199R1 available?
- Yes — 1SDA101199R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
