ABB SACE Tmax XT7L 1600 Moulded-Case Circuit Breaker — Ekip G Dip LS/In, In=800 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT7L 1600 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 800 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip G Dip LS/In (L overload, S short-time-delay, I instantaneous protection). Breaking-capacity class L; rated ultimate short-circuit breaking capacity Icu = 120 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA101538R1, EAN 8056221015820, ABB/SAP material 1200638776, catalogue code 83052589.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT7 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT7L M 800 Ekip G Dip LS/In In=800 3p FF
- ABB order code (MPN)
- 1SDA101538R1
- EAN / GTIN
- 8056221015820
- ABB / SAP material no.
- 1200638776
- Frame
- XT7 (1600 A frame)
- Breaking-capacity class
- L
- Rated ultimate breaking capacity Icu (415 V AC)
- 120 kA
- Trip unit
- Ekip G Dip LS/In
- Rated uninterrupted current In
- 800 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221015820
- SAP 1200638776
- Code 83052589
Product Documentation
More from ABB
ABB
ABB SACE Tmax XT2S 160 Moulded-Case Circuit Breaker — Ekip LS/In, In=63 A, 4-Pole
1SDA067835R1
ABB
ABB SACE Tmax XT2L 160 Moulded-Case Circuit Breaker — TMA 80-800, In=80 A, 3-Pole
1SDA067645R1
ABB
ABB 1SDA051357R1 Electronic TIME Delay 24...30V AC-DC FOR Undervoltage Releas T1..T6-XT1..XT4
ABB
Optisk cable TVOC-1TO2-OP4 4M
ABB
PB 6 Pcs XT5 4P KIT DI.PH.RE
1SDA105009R1
ABB
XT5 W FP 630A 4P frame configurable
1SDA112960R1
ABB
ABB S401M-C40 Miniature Circuit Breaker — 1P, Type C, 40 A, 10 kA
2CCS571001R0404
ABB
END Cover for Busrail
2CDL000001R0001
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA101538R1?
- 1SDA101538R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA101538R1.
- What is the HS code for 1SDA101538R1?
- The customs tariff (HS) code for 1SDA101538R1 is 8536.20.
- Who manufactures 1SDA101538R1?
- 1SDA101538R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA101538R1?
- Yes — the 1SDA101538R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA101538R1?
- The minimum order quantity is 1.
- Is 1SDA101538R1 available?
- Yes — 1SDA101538R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
