ABB SACE Tmax XT7H 1600 Moulded-Case Circuit Breaker — Ekip M Touch LRIU, In=1600 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT7H 1600 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 1600 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip M Touch LRIU. Breaking-capacity class H; rated ultimate short-circuit breaking capacity Icu = 70 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA101473R1, EAN 8056221012874, ABB/SAP material 1200638775, catalogue code 83052542.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT7 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT7H M 1600 Ekip M Touch LRIU 1600 3p FF
- ABB order code (MPN)
- 1SDA101473R1
- EAN / GTIN
- 8056221012874
- ABB / SAP material no.
- 1200638775
- Frame
- XT7 (1600 A frame)
- Breaking-capacity class
- H
- Rated ultimate breaking capacity Icu (415 V AC)
- 70 kA
- Trip unit
- Ekip M Touch LRIU
- Rated uninterrupted current In
- 1600 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221012874
- SAP 1200638775
- Code 83052542
Product Documentation
More from ABB
ABB
ABB 1SDA104766R1 Extended Front Terminals 3PCS FOR Fixed PART XT5 630
ABB
KIT DIN50022 XT4 4P Plate DIN
1SDA080327R1
ABB
Filter 204X204MM RZA300
2CPX046472R9999
ABB
Cover frame TZP509 1350X1250X30MM
2CPX010658R9999
ABB
KLC XT2-XT4 KEY LOCK Ronis EQ.FE.A OP/CL
1SDA066604R1
ABB
ABB SACE Tmax XT4L 160 Moulded-Case Circuit Breaker — Ekip LS/In, In=40 A, 3-Pole
1SDA068551R1
ABB
ABB SACE Tmax XT2L 160 Moulded-Case Circuit Breaker — Ekip In, In=25 A, 4-Pole
1SDA067954R1
ABB
ABB SACE Tmax XT5S 400 Moulded-Case Circuit Breaker — Ekip M Dip LIU, In=320 A, 3-Pole
1SDA100441R1
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA101473R1?
- 1SDA101473R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA101473R1.
- What is the HS code for 1SDA101473R1?
- The customs tariff (HS) code for 1SDA101473R1 is 8536.20.
- Who manufactures 1SDA101473R1?
- 1SDA101473R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA101473R1?
- Yes — the 1SDA101473R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA101473R1?
- The minimum order quantity is 1.
- Is 1SDA101473R1 available?
- Yes — 1SDA101473R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
