ABB SACE Tmax XT7H 1600 Moulded-Case Circuit Breaker — Ekip Hi-Touch LSI, In=1600 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT7H 1600 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 1600 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip Hi-Touch LSI (L overload, S short-time-delay, I instantaneous protection). Breaking-capacity class H; rated ultimate short-circuit breaking capacity Icu = 70 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA101461R1, EAN 8056221012751, ABB/SAP material 1200638617, catalogue code 83054555.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT7 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT7H M 1600 Ekip Hi-Touch LSI 1600 3p FF
- ABB order code (MPN)
- 1SDA101461R1
- EAN / GTIN
- 8056221012751
- ABB / SAP material no.
- 1200638617
- Frame
- XT7 (1600 A frame)
- Breaking-capacity class
- H
- Rated ultimate breaking capacity Icu (415 V AC)
- 70 kA
- Trip unit
- Ekip Hi-Touch LSI
- Rated uninterrupted current In
- 1600 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221012751
- SAP 1200638617
- Code 83054555
Product Documentation
More from ABB
ABB
Contact module E292-16-20
2CCA704300R0001
ABB
ABB 1SDA101988R1 Plate XT5 F FOR Mechanical Interlock REAR Horizontal/Vertical Between 2 C.BREAKERS XT6
ABB
ABB SACE Tmax XT3N 250 Moulded-Case Circuit Breaker — TMD R80, In=80 A, 3-Pole
1SDA068054R1
ABB
ABB S401-D63 Miniature Circuit Breaker — 1P+N, Type D, 63 A, 10 kA
2CCS571103R8631
ABB
ABB 1SDA066634R1 KEY LOCK Ronis Equal ONLY Manual Operation FOR Motor Operator XT2-XT4
ABB
Changeover switch OT315E04CP
ABB
Modular Current Transformer TRFM/250
2CSM100120R1111
ABB
ABB SA/S2.16.6.2 KNX 2-Channel Binary Output 16A with Current Detection
2CDG110269R0011
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA101461R1?
- 1SDA101461R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA101461R1.
- What is the HS code for 1SDA101461R1?
- The customs tariff (HS) code for 1SDA101461R1 is 8536.20.
- Who manufactures 1SDA101461R1?
- 1SDA101461R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA101461R1?
- Yes — the 1SDA101461R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA101461R1?
- The minimum order quantity is 1.
- Is 1SDA101461R1 available?
- Yes — 1SDA101461R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
