ABB SACE Tmax XT7S 1600 Moulded-Case Circuit Breaker — Ekip Hi-Touch LSI IN800, In=800 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT7S 1600 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 800 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip Hi-Touch LSI In800 (L overload, S short-time-delay, I instantaneous protection). Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA101394R1, EAN 8056221012126, ABB/SAP material 1200638612, catalogue code 83054529.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT7 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT7S M 800 Ekip Hi-Touch LSI In800 3p FF
- ABB order code (MPN)
- 1SDA101394R1
- EAN / GTIN
- 8056221012126
- ABB / SAP material no.
- 1200638612
- Frame
- XT7 (1600 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Trip unit
- Ekip Hi-Touch LSI In800
- Rated uninterrupted current In
- 800 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221012126
- SAP 1200638612
- Code 83054529
Product Documentation
More from ABB
ABB
ABB OHBS1PH Selector Handle
ABB
OMB.SET MP T4 4P W UTTR.BAR
1SDA054850R1
ABB
WALL-Mount Cabinet CA46K 1050X950X160MM. IP44
2CPX052299R9999
ABB
RHS L XT1-XT3 F/P EMER. SX Lateral
1SDA066580R1
ABB
ABB SACE Tmax XT2S 160 Moulded-Case Circuit Breaker — In=300 A, 3-Pole
1SDA067746R1
ABB
Polysafe Cabinet 1250X750X320
4TBP833044C0100
ABB
ABB S201M-D6 Miniature Circuit Breaker — 1P, Type D, 6 A, 10 kA
2CDS271001R0061
ABB
Switch-Disconnector T6D 800 A, 3-Pole, Fixed, Front Terminals
1SDA060345R1
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA101394R1?
- 1SDA101394R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA101394R1.
- What is the HS code for 1SDA101394R1?
- The customs tariff (HS) code for 1SDA101394R1 is 8536.20.
- Who manufactures 1SDA101394R1?
- 1SDA101394R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA101394R1?
- Yes — the 1SDA101394R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA101394R1?
- The minimum order quantity is 1.
- Is 1SDA101394R1 available?
- Yes — 1SDA101394R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
