ABB SACE Tmax XT6S 800 Moulded-Case Circuit Breaker — Ekip M Dip In, In=800 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT6S 800 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 800 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip M Dip In. Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA100747R1, EAN 8056221003728, ABB/SAP material 1200638407, catalogue code 83052992.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT6 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT6S 800 Ekip M Dip In In=800A 3p FF
- ABB order code (MPN)
- 1SDA100747R1
- EAN / GTIN
- 8056221003728
- ABB / SAP material no.
- 1200638407
- Frame
- XT6 (800 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Trip unit
- Ekip M Dip In
- Rated uninterrupted current In
- 800 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221003728
- SAP 1200638407
- Code 83052992
Product Documentation
More from ABB
ABB
ABB SACE Tmax XT5S 630 Moulded-Case Circuit Breaker — Ekip Dip LSI, In=630 A, 4-Pole
1SDA100471R1
ABB
Protectionskurv (2CKA006899A2304)
ABB
ABB S804S-B6 Miniature Circuit Breaker — 4P, Type B, 6 A, 50 kA
2CCS864001R0065
ABB
Busplugg EIU32.0 Ethernet IP FOR UMC
1SAJ262000R0100
ABB
ABB SN201-D40 Miniature Circuit Breaker — 1P+N, Type D, 40 A, 6 kA
2CSS255101R0401
ABB
ABB SACE Tmax XT4S 160 Moulded-Case Circuit Breaker — Ekip LSI, In=100 A, 4-Pole
1SDA068503R1
ABB
ABB S402-C0 Miniature Circuit Breaker — 2P, Type C, 0 A, 10 kA 2CCS562001R1984
ABB
Ekip G Dip LS/In XT7/XT7M
1SDA101929R1
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA100747R1?
- 1SDA100747R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA100747R1.
- What is the HS code for 1SDA100747R1?
- The customs tariff (HS) code for 1SDA100747R1 is 8536.20.
- Who manufactures 1SDA100747R1?
- 1SDA100747R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA100747R1?
- Yes — the 1SDA100747R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA100747R1?
- The minimum order quantity is 1.
- Is 1SDA100747R1 available?
- Yes — 1SDA100747R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
