ABB SACE Tmax XT5S 400 Moulded-Case Circuit Breaker — In=100 A, 4-Pole 1SDA100477R1
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT5S 400 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 100 A, 4-pole, F/F (front, fixed) terminals. Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA100477R1, EAN 8056221005548, ABB/SAP material 1200638299, catalogue code 83051973.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT5 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT5S 400 TMG 400-2000 4p FF In=100%In
- ABB order code (MPN)
- 1SDA100477R1
- EAN / GTIN
- 8056221005548
- ABB / SAP material no.
- 1200638299
- Frame
- XT5 (400 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Rated uninterrupted current In
- 100 A
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221005548
- SAP 1200638299
- Code 83051973
Product Documentation
More from ABB
ABB
Residual Current Circuit Breaker WITH Overcurrent DS201 M B6 A30MA
2CSR275180R1065
ABB
ABB SACE Tmax XT2N 160 Moulded-Case Circuit Breaker — TMD R10, In=10 A, 3-Pole
1SDA067008R1
ABB
ABB SACE Tmax XT1N 160 Moulded-Case Circuit Breaker — In=1600 A, 4-Pole
XT1N160TMD160-16004pFFInN=100%
ABB
ABB SACE Tmax XT1N 160 Moulded-Case Circuit Breaker — TMD 63-630, In=63 A, 4-Pole
1SDA067422R1
ABB
ABB S402-Z10 Miniature Circuit Breaker — 2P, Type Z, 10 A, 10 kA
2CCS572001R1108
ABB
ABB SACE Tmax XT5N 400 Moulded-Case Circuit Breaker — MA 320, In=320 A, 3-Pole
1SDA100364R1
ABB
Universaladapter ZLS970N300 (2CCA180561R0001)
ABB
ABB SACE Tmax XT2L 160 Moulded-Case Circuit Breaker — Ekip M-In, In=32 A, 3-Pole
