ABB 1SDA100629R1 Thermomagnetic Release Three-POLE IN AC-DC TMG R 400 I3=1000...2000 XT5
Pricing
Request a quote
We reply within 24 hours
Overview
ABB 1SDA100629R1 Thermomagnetic Release Three-POLE IN AC-DC TMG R 400 I3=1000...2000 XT5 is listed under Electrical Components / Circuit Breaker Accessories. Sales unit: pcs; Environmental Information: 9AKK108467A6707; Product Main Type: Accessories for Tmax XT; Product Type: Accessory; Suitable For: XT5; Configuration Type: Loose or configurable.
Technical Specifications
- Manufacturer part number (MPN)
- 1SDA100629R1
- EAN / GTIN
- 8056221007054
- Sales unit
- pcs
- Number of poles
- 3
- Environmental Information
- 9AKK108467A6707
- Circuit Breaker Type to be Associated
- Generator Protection
- Product Main Type
- Accessories for Tmax XT
- Product Type
- Accessory
- Suitable For
- XT5
- Configuration Type
- Loose or configurable
- Current Type
- AC/DC
- Order Multiple
- 1 piece
- Rated Current (I n )
- 400 A
- Release
- TMG
- Release Type
- TM
- Setting Range
- 280…200 A
- Standards
- IEC60947-2
- Data Sheet, Technical Information
- 1SDC210100D0206; 1SDC210099D0206
- Declaration of Conformity - CE
- Refer to the EU Declaration of the relative Circuit Breaker
- Instructions and Manuals
- 1SDH002011A1518
- ETIM 9
- EC001023 - Shunt release (for power circuit breaker)
- Object Classification Code
- Q
- WEEE Category
- 5. Small Equipment (No External Dimension More Than 50 cm)
- eClass
- V11.1 : 27370418
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 8056221007054
- SAP 1200638257
- Code 83055717
Product Documentation
More from ABB
ABB
IP Switch 8 PORT IS/S 8.1.1
IS/S8.1.1
ABB
ABB 2TMA130160W0036 MIFARE DESFire EV2,works in the outdoor stations which support Desfire functionality
ABB
ABB 2CCA180081R0001 ZLS741 DIN-rail Height Adapter 22.5 mm
ABB
ABB SACE Tmax XT4H 160 Moulded-Case Circuit Breaker — TMA 40-400, In=40 A, 4-Pole
1SDA068350R1
ABB
ED3 Din-rail 3FB 35X15MM
2CPX039383R9999
ABB
IP Touch 10" H8237-4W White LAN-WIFI
2TMA130050W0054
ABB
Tenton 4/8V Black MATT
SB/U8.0.1-885
ABB
SAGA Kortswitch 2-Pole with Frame
2TKA00005291
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
