ABB SACE Tmax XT5H 400 Moulded-Case Circuit Breaker — TMA 320-3200, In=320 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT5H 400 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 320 A, 3-pole, F/F (front, fixed) terminals. Thermomagnetic trip unit TMA 320-3200 (adjustable thermal overload and magnetic short-circuit release). Breaking-capacity class H; rated ultimate short-circuit breaking capacity Icu = 70 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA100484R1, EAN 8056221005616, ABB/SAP material 1200638223, catalogue code 83055676.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT5 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT5H 400 TMA 320-3200 3p FF
- ABB order code (MPN)
- 1SDA100484R1
- EAN / GTIN
- 8056221005616
- ABB / SAP material no.
- 1200638223
- Frame
- XT5 (400 A frame)
- Breaking-capacity class
- H
- Rated ultimate breaking capacity Icu (415 V AC)
- 70 kA
- Trip unit
- TMA 320-3200
- Rated uninterrupted current In
- 320 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221005616
- SAP 1200638223
- Code 83055676
Product Documentation
More from ABB
ABB
Kl_a STI Arrangement FP XT5-XT6
1SDA105111R1
ABB
ABB SACE Tmax XT2H 160 Moulded-Case Circuit Breaker — TMD 4-40, In=4 A, 3-Pole
1SDA067588R1
ABB
ABB SACE Tmax XT7H 1600 Moulded-Case Circuit Breaker — Ekip Hi-Touch LSI, In=1250 A, 4-Pole
1SDA101740R1
ABB
ABB E290-16-11/115 impulse relay, 16 A, 115 V AC / 60 V DC
ABB
MBK110 Terminal block module
2CPX041701R9999
ABB
ABB SACE Tmax XT5S 400 Moulded-Case Circuit Breaker — Ekip M Dip LIU, In=250 A, 3-Pole
1SDA100440R1
ABB
Busklemme White/Yellow (konnektor HVID/Yellow)
KONNEKTOR HVID/GUL
ABB
ABB SACE Tmax XT2S 160 Moulded-Case Circuit Breaker — Ekip LSI, In=63 A, 4-Pole
1SDA067847R1
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA100484R1?
- 1SDA100484R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA100484R1.
- What is the HS code for 1SDA100484R1?
- The customs tariff (HS) code for 1SDA100484R1 is 8536.20.
- Who manufactures 1SDA100484R1?
- 1SDA100484R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA100484R1?
- Yes — the 1SDA100484R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA100484R1?
- The minimum order quantity is 1.
- Is 1SDA100484R1 available?
- Yes — 1SDA100484R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
