ABB SACE Tmax XT5S 400 Moulded-Case Circuit Breaker — Ekip M Dip In, In=320 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT5S 400 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 320 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip M Dip In. Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA100437R1, EAN 8056221005142, ABB/SAP material 1200638185, catalogue code 83055668.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT5 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT5S 400 Ekip M Dip In In=320A 3p FF
- ABB order code (MPN)
- 1SDA100437R1
- EAN / GTIN
- 8056221005142
- ABB / SAP material no.
- 1200638185
- Frame
- XT5 (400 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Trip unit
- Ekip M Dip In
- Rated uninterrupted current In
- 320 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221005142
- SAP 1200638185
- Code 83055668
Product Documentation
More from ABB
ABB
ABB 2CSG225785R1101 CT PRO XT 100 A / 5 A Current Transformer Class 0.5
ABB
Ekip Dip LSI XT7/XT7M
1SDA101919R1
ABB
ABB SACE Tmax XT2N 160 Moulded-Case Circuit Breaker — In=160 A, 4-Pole 1SDA067729R1
ABB
ABB SACE Tmax XT4L 160 Moulded-Case Circuit Breaker — Ekip LSI, In=100 A, 3-Pole
1SDA068563R1
ABB
ABB 1SDA066601R1 KEY LOCK Ronis Equal Fellow B IN OPEN WITH KEY Withdrawable IN OPEN Position FOR C.BREAKER XT2-XT4
ABB
ABB SACE Tmax XT5N 400 Moulded-Case Circuit Breaker — Ekip M Dip LIU, In=250 A, 3-Pole
1SDA100370R1
ABB
ABB S402-C3 Miniature Circuit Breaker — 2P, Type C, 3 A, 10 kA 2CCS572001R1034
ABB
ABB SACE Tmax XT5N 400 Moulded-Case Circuit Breaker — Ekip Dip LS/In, In=250 A, 3-Pole
1SDA100352R1
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA100437R1?
- 1SDA100437R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA100437R1.
- What is the HS code for 1SDA100437R1?
- The customs tariff (HS) code for 1SDA100437R1 is 8536.20.
- Who manufactures 1SDA100437R1?
- 1SDA100437R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA100437R1?
- Yes — the 1SDA100437R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA100437R1?
- The minimum order quantity is 1.
- Is 1SDA100437R1 available?
- Yes — 1SDA100437R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
